Chassis System - KENT Razor Plus 24C Parts List

2004-12

CHASSIS SYSTEM

RAZOR
TM
2006-02
Item No. Ref. No.
1# 909 6032 000
2 xxx xxxx xxx
3 146 0987 000
4 xxx xxxx xxx
5 909 5193 000
6 08812361
7 xxx xxxx xxx
8 909 5186 000
9 xxx xxxx xxx
10 xxx xxxx xxx
11 145 8053 000
12 909 5182 000
13 145 4284 000
14 xxx xxxx xxx
15 xxx xxxx xxx
16 145 6062 000
17 xxx xxxx xxx
18 xxx xxxx xxx
19 909 5164 000
20 xxx xxxx xxx
21 xxx xxxx xxx
22 xxx xxxx xx
23 xxx xxxx xxx
24 xxx xxxx xxx
25 xxxxxxxx
26 909 5184 000
27 xxx xxxx xxx
28 909 5194 000
29 xxx xxxx xxx
30 xxxxxxxx
31 xxx xxxx xxx
32 xxx xxxx xxx
33 xxx xxxx xxx
34 56325601
35 909 5190 000
36 xxx xxxx xxx
37 xxx xxxx xxx
38 909 5183 000
39 xxx xxxx xxx
40 909 5393 000
41 909 5181 000
42 909 5449 000
43 146 1555 000
44 909 5390 000
45 909 5391 000
46 909 5392 000
47 145 4523 000
48 145 9120 000
49 xxxxxxxx
50 08603688
51 145 9133 000
52 145 9669 000
53 909 5804 000
54 145 9170 000
55 56325587
56 909 5891 000
57 56003389
58# 145 1235 000
Plus 24D/ 26D/ 28D/ 24C/ 28C
Qty Description
1 Actuator 24V (TSB 2005-022)
1 Cable, stainless steel (Handwheel kit)
3 Clamp
2 Spring (Hardware fixing kit)
1 Spring
2 Washer
1 Washer (Lever kit)
1 Support
2 Head articulated M10 (Bar thd kit)
1 Handwheel (Handwheel kit)
1 Vibration damping, Razor
2 Vibration damping
2 Vibration damping
2 Washer (Hardware fixing kit) (Lever kit)
1 Washer (Bar thd kit) - (Hardware fixing kit)
1 Connector
5 Washer (Lever kit)(Hardware fixing kit)
1 Washer (Handwheel kit)
1 Chassis
2 Screw hex hd M10x55 (Lever kit) - (Hardware fixing kit)
2 Screw hex hd M12x20 (Hardware fixing kit)
1 Screw hex hd M12x30 (Lever kit)
2 Screw hex hd M12x20 (Hardware fixing kit)
1 Screw hex hd M5x12 (Handwheel kit)
1 Screw hex hd M8x25 (Handwheel kit)
1 Tube, jack motor
2 Spacer (Lever kit) - (Hardware fixing kit)
4 Nut hex selflock M10
1 Nut hex selflock M10 (Hardware fixing kit)
1 Nut hex selflock M12 (Hardware fixing kit)
1 Nut hex M8 (Lever kit)
2 Nut hex M10 (Bar thd kit)
1 Nut hex M5 (Handwheel kit)
1 Nut hex M8, Razor
TM
1 Bracket
1 Screw hex hd M12x160 (Hardware fixing kit)
1 Lever (Lever kit)
2 Lever
1 Bar thd M10x185 (Bar thd kit)
1 Bar thd kit(9-15-32-39)
1 Battery container
1 Harness machine
2 Vibration damping
1 Handwheel kit (2-10-18-24-25-33)
1 Hardware fixing kit (4-14-15-17-20-21-23-27-29-30-36-49)
1 Lever kit (7-14-17-22-27-31-37-58)
2 Nut hex low M8
2 Washer flat 8x17
2 Nut hex M10 (Hardware fixing kit)
1 Nut hex low M5 selflocking SS, Razor
1 Washer flat 5x10,Razor
1 Screw M5x20,Razor
TM
1 Hose clamp ø16,Razor
1 Screw hex hd M8x20
2 Washer flat 8x17
1 Cable tank block
1 Nut hex self lock M8, Razor
1 Screw M10X60 (Hardware fixing kit)
Plus 24D/ 26D/ 28D
TM
Plus 24D/ 26D/ 28D
Plus 24C - 28C
TM
Plus 24C - 28C
TM
Plus 24C - 28C
Plus 24C - 28C
TM
Plus 24C - 28C
TM
9
909 5429 000(3)2006-02
