Solution System - KENT Razor Plus 24C Parts List

2004-12

SOLUTION SYSTEM

RAZOR
TM
2006-02
Item No. Ref. No.
1 56325638
2 909 5207 000
3 xxx xxxx xxx
4 145 9228 000
6 xxxxxxxx
7 xxx xxxx xxx
8# xxx xxxx xxx
9 xxx xxxx xxx
10 909 5210 000
11 909 5443 000
12 145 9233 000
13 xxx xxxx xxx
14 145 9128 000
15 xxx xxxx xxx
16 xxxxxxxx
17 145 9261 000
18 08091200
19 xxx xxxx xxx
20 xxx xxxx xxx
21 xxx xxxx xxx
22 xxx xxxx xxx
23 xxx xxxx xxx
24 xxx xxxx xxx
25# xxx xxxx xxx
26 xxx xxxx xxx
27# 909 5477 000
28# 909 5395 000
29 xxx xxxx xxx
30 909 5622 000
31 909 5787 000
32# 909 6046 000
Plus 24D/ 26D/ 28D/ 24C/ 28C
Qty Description
1 Clamp
1 Water filter (Solenoid valve kit)
1 Valve (Kit valve complete-Kit valve with pipe holder)
2 Washer 6
1 Valve (Solenoid valve kit -Valve kit)
1 Nipple (Solenoid valve kit)
1 Net, water filter w/gasket (Solenoid valve kit)
1 Washer split 5 (Solenoid valve kit -Valve kit)
1 Support, solenoid valve
1 Solenoid valve 24V (Solenoid valve kit)
1 Washer
2 Washer flat 5x10 (Solenoid valve kit)
2 Washer 6x12,5
1 Washer flat 5x20 (Solenoid valve kit -Valve kit)
1 Clamp (Solenoid valve kit)
3 Screw hex hd M6x16
1 Nut hex M6
2 Screw socket hd M4x8 SS (Solenoid valve kit)
1 Pipe holder female 1/2 - 90° (Kit valve complete)
1 Pipe holder straight male 1/2 (Solenoid valve kit)
1 Lever (Solenoid valve kit -Valve kit)
1 Hose ø10 length 460 mm (Kit valve complete)
2 Pipe holder ø11 (Kit valve complete-Kit valve with pipe holder)
2 Clamp (Kit valve complete)
1 Hose ø10 550 mm (Solenoid valve kit)
1 Solenoid valve kit (2-6-7-8-9-11-13-15-16-19-21-22-26-29)
1 Kit valve complete (3-20-23-24-30)
1 Gasket (Solenoid valve kit)
1 Hose ø10 length 640 mm (Kit valve complete)
1 Kit valve with pipe holder (3-24)
1 Valve kit (6-9-15-22)
15
909 5429 000(3)2006-02
