7.5 Viewing the Quicklog Data and Snapshot Data History: Navigation Keypad

Select the Logging icon ① from the Navigation Carousel to display the Logging

screen.

Select the lower Navigation key ② to highlight the function.

Select OK ③.

Using the navigation keys select Quicklog Data ④ or Snapshot Data ⑤.

Select OK ③.

Using the Navigation keys select the required file ⑥. NOTE: The time and date that

the file was created is displayed in the second (lower) screen.

Select OK ③ to display the file graph ⑦.

Select OK ③ to display the file information ⑧ and print ⑨ icons.

Select the file information icon ⑧ to display the file information ⑩. NOTE: the

information will clear after a short period and be replaced by the file graph display

⑦.

10. Select the print icon (9) to print the file.

11. Select BACK ⑪ to return to the file graph display ⑦, Quicklog Data ④ or

Snapshot Data ⑤ screen and Logging screen.
