7.2 Data Logging

1.
Select the Home icon ① from the Navigation Carousel to display the Home screen.
2.
Select the upper navigation key ② to display the Graph screen.
3.
Select OK ③ to display the Data Logging icon ④.
4.
Using the navigation keys highlight the Data Logging icon (4).
5.
Select OK ③.
6.
Using the navigation keys select the Location ID ⑤.
NOTE Data Logging information will be saved under the Location ID selected. Open
this file when viewing the data with the User Tool software.
7.
Using the navigation keys select the (Data Logging) Interval (6). NOTE: The
SADPmini2-Ex has an Interval range of five seconds to one hour. The file will
contain 1000 samples. The Duration (measured in hours, minutes and seconds) will
automatically be calculated to the parameters of the interval selected ⑦.
8.
Using the navigation keys highlight the Start dialogue box ⑧.
9.
Select OK ③ to start the Data Logging process. NOTE: The Graph screen will be
displayed. A red flashing indicator ⑨ will be displayed. Data Logging is in progress.
10. Select OK ③ to access the Data Logging Stop ⑩, and Data Logging screen
snapshot ⑪ and Data Logging print⑫
11. If required, select the Data Logging Stop ⑩ function. NOTE Data Logging will stop.
The red flashing indicator ⑨ will not be displayed. Data Logging is no longer in
progress. Data Logging will be saved in the Location ID selected above (Point 6).
12. If required, select the Data Logging snapshot ⑪ function. A snapshot of the Data
Logging display screen will be saved on the SD Card in the Location ID selected
above (Point 7). NOTE Screen snapshots are possible during the Data Logging
process by activating the Snapshot icon.
13. If required, select the Data Logging print ⑫ function. The Data Logging information
will be printed using a Bluetooth printer. The printer icon is green when paired and
connected. If a printer is not paired the user will be taken to the Bluetooth Printer
set up. NOTE: Data printouts are possible during the Data Logging process by
activating the printer icon.
14. Select Home ⑬ to return to the Home screen.
SADPmini2-Ex User Manual
35
