4.3 Navigation Carousel

The different instrument functions are accessed using the Navigation Carousel.
Navigation icons on the carousel relate to the five different screen options available.
The Navigation arrows displayed to the left and right of the Navigation Icons indicate the
other screens that can be accessed after selecting one of the five Navigation icons.
No. Description
1 Navigation Keys (left and up)
2 Information (icon)
3 Bluetooth (icon)
4 Home (icon)
5 Logging (icon)
6 Settings (icon)
7 Navigation Keys (right and down)
Selecting an icon on the Navigation Carousel will display the associated screen.
