It is the responsibility of the user to ascertain the suitability of the SADPmini2-Ex for use
in hazardous areas. Risk assessments should be carried out prior to use, taking into
account the SADPmini2-Ex certifications, location and the gas being monitored.
2.3

Symbols Table

Symbol
SADPmini2-Ex User Manual
Description
Lithium-ion Battery
The SADPmini2-Ex is powered by a single lithium-ion battery.
Only use the USB power supply supplied with the instrument to charge
the battery.
It is recommended that the SADPmini2-Ex be put on charge overnight
prior to use
Pressure Exposure
The telescopic measuring head should not be exposed to
Exposing the measuring head to higher pressures may
damage the instrument and result in injury to the
operator or other personnel in the area.
USB Communication Performance
Using the USB communication channel and charging power port within
the instrument may result in not all connections to all USB ports on all
PCs or laptops being entirely successful. Many USB ports, even within the
same PC or laptop, differ from each other in electrical hardware or
firmware implementations, whilst still broadly complying with the overall
USB standards, giving rise to a variety of situations which may manifest in
a reduced connection experience. It is recommended that if a port is not
connecting as expected then the user should try an alternative port
within the PC or laptop or employ a USB Hub device which would
effectively isolate the problematic PC or laptop USB port from the
instrument.
more than 0.3 barg, 4 psig
