7.3 QuickLog

Select the Home icon ① from the Navigation Carousel to display the Home screen.

Select the upper navigation key ② to display the Graph screen.

Select OK ③ to display the Quicklog ④ icon.

Using the navigation keys highlight the Quicklog ④ function.

Select OK ③ to start the Quicklog process. NOTE: The Graph screen will be

displayed. A red flashing indicator ⑤ will be displayed. Quicklog is in progress.

Select OK ③ to display the Quicklog stop ⑥, Quicklog print ⑦ and Quick Logging

screen snapshot ⑧ icons. Quicklog is set at a 5 second sample speed for up to 240

samples.

If required, using the navigation keys select the Quicklog Stop ⑥ function. NOTE:

Quicklog will stop. The red flashing indicator ⑤ will not be displayed. Quicklog is

no longer in progress.

If required, using the Navigation keys select the Quicklog print ⑦ function. The

Quicklog information will be printed using a Bluetooth printer. If a printer is not

paired the user will be taken to the Bluetooth Printer set up.

NOTE: Screen printouts are possible during the Quicklog process by activating the

Snapshot icon.

Select the Quicklog snapshot ⑧ function if required. A snapshot of the Quicklog

display screen will be saved in the selected Location ID. NOTE: Screen snapshots

are possible during the Quicklog process.

10. Select Home ⑨ to return to the Home screen.
