SolConeX Wall-Mounted Socket, 16 A
Series 8570/11
Operating instructions
Additional languages www.r-stahl.com
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SolConeX 8570/1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stahl SolConeX 8570/1 Series

Summary of Contents for Stahl SolConeX 8570/1 Series

  • Page 1 Operating instructions Additional languages www.r-stahl.com SolConeX Wall-Mounted Socket, 16 A Series 8570/11...

  • Page 2: Table Of Contents

    Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Further documents ....................3 Conformity with standards and regulations ............3 Explanation of the symbols .................4 Symbols in these operating instructions .............4 Warning notes .....................4 Symbols on the device ..................5 Safety notes ......................5 Operating instructions storage ................5 Personnel qualification ..................5...

  • Page 3: En En

    • Datenblatt Steckvorrichtungen SolConeX & CES Dokumente in weiteren Sprachen, siehe www.r-stahl.com. Conformity with standards and regulations See certificates and EU Declaration of Conformity: www.stahl-ex.com. The device has IECEx approval. See IECEx homepage: http://iecex.iec.ch/ Further national certificates can be downloaded via the following link: https://r-stahl.com/en/global/products/support/downloads/.

  • Page 4: Explanation Of The Symbols

    Explanation of the symbols Explanation of the symbols Symbols in these operating instructions Symbol Meaning Tips and recommendations on the use of the device General danger Danger due to explosive atmosphere Danger due to energised parts Warning notes Warning notes must be observed under all circumstances, in order to minimize the risk due to construction and operation.

  • Page 5: Symbols On The Device

    • Use the device in accordance with its intended and approved purpose only. • Always consult with R. STAHL Schaltgeräte GmbH if using the device under operating conditions which are not covered by the technical data. • Before installation, make sure that the device is not damaged.

  • Page 6: Modifications And Alterations

    Function and device design For mounting and installation • Have mounting and installation performed only by qualified and authorised persons (see "Personnel qualification" section). • The device is only to be installed in zones for which it is suited based on its marking. •...

  • Page 7: Technical Data

    Technical data Technical data Explosion Protection Global (IECEx) Gas and dust IECEx PTB 05.0023 Ex db eb IIC T6 Gb Ex db eb ia IIC T6 Gb Ex tb IIIC T80°C Db Europe (ATEX) Gas and dust PTB 03 ATEX 1227 E II 2 G Ex db eb IIC T6 Gb E II 2 D Ex tb IIIC T80°C Db Special version...
  • Page 8 Technical data Technical Data Rated insulation 8570/11-3.. : 550 V voltage 8570/11-4.. : 750 V 8570/11-5.. : 750 V Auxiliary contacts: 550 V Back-up fuse without thermal 16 A gG protection with thermal 35 A gG protection Ambient conditions Ambient temperature -30 ... +55 °C -50 °C on request (internal lubrication using silicone grease) Mechanical data Number of poles...

  • Page 9: Transport And Storage

    External earth Positioning at side acc. to order possible (connection cross-section 10 mm connection For further technical data, see www.r-stahl.com. Transport and storage • Transport and store the device only in the original packaging. • Store the device in a dry place (no condensation) and vibration-free.

  • Page 10: Mounting And Installation

    Mounting and installation Mounting and installation Dimensions / fastening dimensions Dimension drawings (all dimensions in mm) - subject to alterations 10338E00 10333E00 8570/11-3.. 8570/11-4.. and 8570/11-5.. Arrangement of the earth contact sleeve Position: clock hour position, view: front side of the socket Example: Clock hour position 19178E00...
  • Page 11 Mounting and installation Colour code and arrangement of socket contacts and terminal markings No. of poles Frequency Voltage Colour code Position of earth [Hz] contact sleeve 8570/11-3.. 50 and 60 200 to 250 blue 2 P + ¿ 50 and 60 380 to 415 50 and 60 480 to 500...

  • Page 12: 7.2 Mounting / Dismounting, Operating Position

    Mounting and installation Mounting / dismounting, operating position 7.2.1 Assembly This device is suitable for outdoor and indoor use. • Provide a protective roof or wall if the enclosure and explosion-protected electrical equipment are used outdoors. Operating position • Hinged cover facing downwards, connection chamber facing upwards.

  • Page 13: Installation

    Mounting and installation Installation WARNING Danger of electric shock due to energised parts! Non-compliance can result in severe or fatal injuries. • All connections and wiring must be disconnected from the power supply. • Secure the connections against unauthorized switching. DANGER Explosion hazard due to insufficient protective measures! Non-compliance results in severe or fatal injuries.
  • Page 14 Mounting and installation • Open the enclosure. Guide the cables through the cable entry into the connection chamber. Strip the cables. Insert the conductors into the corresponding terminals and clamp them (for tightening torque, see chapter "Technical data"). Insert the stripped cable ends completely 11201E00 under the clamping plate.

  • Page 15: Commissioning

    If the plug has been disconnected, close the hinged cover with the bayonet ring. Only type 8570/12 and 8575/12 plugs from R. STAHL may be used. The degree of protection of the 8575/12 plug is reduced to IP55 when plugged in.

  • Page 16: Maintenance, Overhaul, Repair

    10.3 Repair DANGER Explosion hazard due to improper repair! Non-compliance results in severe or fatal injuries. • Repair work on the devices must be performed only by R. STAHL Schaltgeräte GmbH. 150646 / 8570601300 SolConeX Wall-Mounted Socket, 16 A Series 8570/11...

  • Page 17: 10.4 Returning The Device

    Only return or package the devices after consulting R. STAHL! Contact the responsible  representative at R. STAHL for this. R. STAHL's customer service is available to handle returns if repair or service is required. Only return or package the devices after contacting and consulting R. STAHL! Contact customer service personally.

This manual is also suitable for:

Solconex 8570/2 seriesSolconex 8570/5 seriesSolconex 8570/6 series
