MAINTAINING YOUR VACUUM
CLEANING THE AUTO-EMPTY DOCK FILTER
FPO
To access the filter in the dock, remove the
filter door. Press the button at the bottom
of the door, then tilt the door and lift it off.
Remove the filter from the dock. After the
filter has been rinsed and dried, reinstall it
by reinserting it into the dock and replacing
the filter door.
For best results, clean the Auto-Empty filters at least once a month and replace the filters regularly. To clean filters, rinse with cold water
ONLY to prevent damage from cleaning chemicals. Allow all filters to air-dry for at least 24 hours before reinstalling them to prevent
liquid from being drawn into electrical parts. Maintaining the Exhaust Foam Filter will ensure successful Auto-Empty evacuation.

NOZZLE MAINTENANCE

Fig. 1
FPO
POWERFIN FLOOR NOZZLE
1. Turn off the vacuum.
2. Press the nozzle release button to detach
the nozzle from the wand (Fig. 1).
3. Turn the nozzle over and use a screwdriver
to loosen the screws to the unlocked
position (Fig. 2).
s h a r kc l e a n . c o m
FPO
To access the Auto-Empty Exhaust Foam
Filter, remove the dust bin. Before removing
the exhaust foam filter, vacuum off any fine
debris from the surface. Lift the filter out
of the dock, then rinse it with water only
(do not use soap). Allow the filter to air-dry
completely before reinstalling it.
FPO
Fig. 2
Fig. 3
FPO
4. Once unlocked, remove the soleplate from
the nozzle (Fig. 3).
5. When reinserting the soleplate, make sure
to turn the screws to the locked position.
MAINTAINING YOUR VACUUM

CLEANING THE SENSORS

Fig. 1
Air path
Dust cup
Battery
DIRT DETECT SENSORS
Fig. 2
LIGHT DETECT SENSOR
CLEANING THE HAND VACUUM DUST CUP (IP3000)
Fig. 1
FPO
1. To remove the dust cup on your IP3000
hand vacuum, press the release button
and slide the dust cup off the hand vac
(Fig.1).
Make sure to clean the Detect sensors
regularly, as hair and other debris may build
up and obstruct them. If the sensors are
partially obstructed, DETECT mode will not
function as expected.
To clean the sensors :
1. Turn off power and remove the floor nozzle.
2. Locate the Dirt Detect sensor in the nozzle
of the hand vac (Fig. 1), the Light Detect™
sensor on the top of the nozzle (Fig. 2),
and the Edge Detect sensor on the side of
the nozzle (Fig. 3).
3. Gently wipe the sensors with a microfiber
cloth and remove all hair and debris.
4. Reattach the floor nozzle to the rest of the
unit and turn on power. Verify that the unit
is functioning normally.
Fig. 3
EDGE DETECT SENSOR
Fig. 2
FPO
2. Press the Dust Cup Empty button to open
the dust cup lid. (Fig 2).
