Shark POWERDETECT IP1000 Series Quick Start Manual

Please be sure to read and save the warnings on other side prior to using your unit.
How to set up and use the IP1000 Series Shark
ASSEMBLY
1. Slide the Wand onto the neck of the
Floor Nozzle until it clicks into place.
2. Align the Hand Vacuum nozzle
opening with the top of the wand and
slide it on until it clicks into place.
For proper operation, ensure all
components are completely connected
and clicked into place.
Handheld
Vacuum
2.
(Click)
MultiFlex®
Wand
1.
(Click)
Floor Nozzle
MULTIFLEX
MULTIFLEX
If your vacuum model includes the
MultiFLEX wand, you can adjust the
angle to clean under furniture and in
other hard-to-reach areas. Press the
latch on the back of the wand to
adjust the angle. To return to the
original angle, straighten the wand
until it clicks securely into place.
EMPTYING THE DUST CUP
To empty the dust cup, hold the hand
vacuum at a 45-degree angle over
the trash, then press the latch on
the front of the hand vac. The dust
cup will drop open, releasing dust
and debris into the trash. To close,
push the dust cup back into place.
QUICK START GUIDE
CHARGING
CHARGING BATTERY
IN HANDHELD VACUUM
To charge the battery inside the
handheld vacuum, connect the
charger to an electrical outlet,
then insert the charger plug into
the port below the handle on the
handheld vacuum.
NOTE: You may purchase an extra
battery and charger for your vacuum
cleaner from sharkclean.com.
NOTE: The main unit comes with
a partial charge. For maximum
runtime, charge fully before first use
(approximately 6 hours). Leaving
the unit plugged in will not damage
battery life.
AND STORAGE
®
FLEX STORAGE
Press the MultiFLEX latch on the
back of the wand and fold the
vacuum down into storage position.
Please ensure the vacuum dust cup
is empty before storing.
Cordless POWERDETECT
®
POWER ON/OFF
Press the On/
Off button on the
handle to turn on
power. To turn off
power, press the
button again.
BATTERY CHARGING INFORMATION
Full Charge Half Charge
MODES EXPLAINED
ECO MODE Maximizes runtime
DETECT MODE
Detect technology is ONLY activated in Detect mode and is activated automatically
when the unit is in use.
Dirt Detect: Identifies
dirtier high-traffic areas and
automatically boosts suction
power to pull in hidden dirt.
Clean Floor Medium Dirt
Low Suction Medium Suction
EDGE DETECT
Edge Detect: Dynamically detects edges and corners while
maximizing suction power to remove stubborn dirt.
Floor Detect : The brushroll responds to surface changes and
™
automatically adjusts to optimize your clean.
Light Detect : Senses low-light situations and automatically
™
illuminates dark areas to help you spot debris.
BOOST MODE Maximizes suction
IMPORTANT: FILTER CLEANING
1. To access the HEPA filter, press
the dust cup empty button to
release the dust cup.
NOTE: Rinse the HEPA filter at least once a month to maintain suction power. More frequent
cleaning may be necessary with heavy use. To clean the filter, rinse it with water only and
allow it to air-dry completely for up to 48 hours before reinstalling. Tap off loose dirt between
washes when needed.
IMPORTANT: DO NOT use soap when cleaning the filters. Use water only. The vacuum will not
have suction if the post-motor filter is not installed. Ensure that all filters are installed before using.
Vacuum.
™
MODE SELECTION TRIGGER
To toggle
between ECO,
DETECT, and
BOOST modes,
press the mode
selection trigger.
Blinking
Low Charge
SENSES YOUR ENVIRONMENT TO
OPTIMIZE YOUR CLEANING EXPERIENCE.
NOTE: Hand Vacuum
Heavy Dirt
UI and Nozzle Lights
High Suction
are Synched.
2. Grip the filter by the tab and slide
it out of the hand vac.
3. After the filter has been rinsed
and air-dried completely, slide it
back into the hand vacuum.
No Charge
