Battery Specifications; Battery Replacement - Fenix HM62-T Manual

With the lamp switched off, quickly double click the button to enter red light mode.
Output selection
White light mode: single click the switch to cycle through Low→Med→High→Turbo.
Red light mode: single click the switch to cycle through Constant-on→Flash.
Lockout Function
Lock: with the lamp switched off, press and hold the switch for 3 seconds, the lamp will blink 4 times on the Low
output of white light mode to indicate locked status.
Unlock: with the lamp locked, press and hold the switch for 3 seconds, the lamp will be activated on the Low
output of white light mode.
In locked status, clicking or pressing the switches will activate 4 blinks on the Low output of white light mode to
indicate locked status.

Battery Specifications

Type
Fenix ARB-L18 Series
Fenix ARB-L16 Series
Non-rechargeable Battery
(Li-ion)
Rechargeable Battery (Li-ion)
*18650 Li-ion batteries are powerful cells designed for commercial applications and must be treated with caution
and handled with care. Only use quality batteries with circuit protection will reduce the potential for combustion
or explosion; but cell damage or short circuiting are potential risks the user assumes. Quality Li-ion battery with
protective circuit will reduce risks.

Battery Replacement

Unscrew the battery cover counterclockwise to insert the battery in accordance with the polarity marks, then
screw the battery cover back on.
Charging
1. Turn off the light and unscrew the battery cover counterclockwise to take out the battery, then connect the
USB Type-C end of the charging cable to the battery.
2. The indicator of the battery will display red while charging, and will turn blue when fully charged.
Dimensions Nominal voltage
18650 3.6 V
16340 3.6 V
CR123A 3.0 V
18650 3.6 V
Usability
Recommended √√
Usable
√
Usable
√
！
Caution*
