Sunricher SR-ZG2836D5 Instructions

Zigbee Smart Remote
Important: Read All Instructions Prior to Installation
Function introduction
LED indicator
Network pairing/reset
1. Quickly short press the 2. Immediately long press the
center button 5 times center button for 3 seconds.
Keys and rotary function setting
After adding the remote into Azoula, then you can choose and tap each button or rotary to customize the function
Clockwise rotation
Rotation Anticlockwise rotation
Center
Short press
Long press
Double click
Product Data
• Smart zigbee 3.0 standard remote with 5 push keys and 1 rotary
• ALL keys and rotary function can be customized through Azoula
APP
• Battery powered with low power consumption
• Magnet built-in, desktop or standard EU/US wall mounted
bracket for optional
• Lights, zones, and scenes control can be customized
Protocol ZigBee 3.0
Operation Voltage 3VDC (CR2450 battery)
Transmission Frequency 2.4GHz
Transmission Range (free field) 30m
Φ58x20mm
Dimension
Waterproof Grade IP20
Flash If the remote had not been added into an
Azoula gateway before, it will be found
and added into the network, or the state
will last for 3 minutes.
If the remote had been added into a
network before, it will be removed from
the network and into network pairing mode
again.
3. The red LED indicator flash.
The remote into network pairing
mode or reset mode.
Target
Lights
Zones
Target Action
Lights
Zones
Scenes
Replace Battery
1. Use a coin to open the battery 2. Exchange the battery
cover in the direction indicated
Installation bracket
1
Method 1:Stick 3M glue on the Method 2:Screw the bracket
back of the bracket and then stick to the wall
the bracket to the wall
3
Magnetic
3. Use a coin to secure the battery
cover in the direction indicated
2
4
