  • Page 1 C-BOX 300/310 Installation Manual...
  • Page 3 C-BOX 300/310 INSTALLATION MANUAL...
  • Page 4 Datalogic S.p.A. reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    CONTENTS GUIDE TO INSTALLATION .................iv GENERAL VIEW ..................v SAFETY PRECAUTIONS................x Power Supply....................x Safety Notes ....................x GENERAL FEATURES ................1 Description ....................1 INSTALLATION.................... 2 Package Contents..................2 Opening the Device ..................3 Applying the Adhesive Label................. 4 Mechanical Installation..................

  • Page 6: Guide To Installation

    GUIDE TO INSTALLATION The following can be used as a checklist to verify all of the steps necessary for complete installation of the C-BOX 3X0. 1) Read all information in the section "Safety Precautions" at the beginning of this manual. 2) Correctly position and mount the C-BOX 3X0 within the reach of the barcode scanner cable, according to the information in paragraph 2.4.

  • Page 7: General View

    GENERAL VIEW C-BOX 300 Figure A 25-pin scanner connector Compression connectors Cover screws (4) Profibus connector...
  • Page 8 C-BOX 310 Figure B LCD display Keypad...
  • Page 9 C-BOX 300/310 Figure C - Cover inside Configuration switch Diagnostic LED 1 LCD contrast trimmer Diagnostic LED 2 Diagnostic LED 3 Power on LED Node address selectors Tx LED...
  • Page 10 C-BOX 300 Figure E - Bottom inside Power on switch SEND button Chassis grounding selector Auxiliary port connector OM4000 jumpers Spring clamp terminal blocks Warning LED GET button TEST button viii...
  • Page 11 C-BOX 310 Figure D - Bottom inside...

  • Page 12: Safety Precautions

    SAFETY PRECAUTIONS POWER SUPPLY ATTENTION: READ THIS INFORMATION BEFORE INSTALLING THE PRODUCT - This product is intended to be installed by Qualified Personnel only. The C-BOX 3X0 is intended to be supplied either by a UL Listed NEC Class 2 power source, or a UL Listed ITE Limited Power Source (LPS), rated 10-30 V dc, minimum 0.5 A.
  • Page 13 Terminating resistors Terminating resistors must be used if the C-BOX is installed at the beginning or end of the PROFIBUS cable segment. In this case, it is recommended to use PROFIBUS connectors which contain an integrated terminating resistor. It is recommended to use connectors from ERNI and Siemens.

  • Page 15: General Features

    In the C-BOX 310, visualize the data packet sent by the scanner on the LCD. The C-BOX 300 / C-BOX 310 mechanical dimensions are 167 x 115 x 61 mm (6.57 x 4.53 x 2.40 in.). The C-BOX 300 weighs about 440 g (15.50 oz); the C-BOX 310 weighs about 500 g (17.60 oz).

  • Page 16: Installation

    C-BOX 300/310 2 INSTALLATION PACKAGE CONTENTS Verify that the C-BOX 3X0 and all the parts supplied with the equipment are present and intact when opening the packaging; the list of parts includes: C-BOX 3X0 Installation manual C-BOX 3X0 configuration program disk...

  • Page 17: Opening The Device

    To install the C-BOX 3X0 or during normal maintenance, it is necessary to open it by unscrewing the four cover screws: The C-BOX 3X0 must be disconnected from the power supply during this operation. CAUTION C-BOX 300 C-BOX 310 Figure 2 - Opening the C-BOX 3X0 It is possible to perform the following operations: •...

  • Page 18: Applying The Adhesive Label

    C-BOX 300/310 APPLYING THE ADHESIVE LABEL The C-BOX 3X0 equipment includes a rectangular adhesive label designed to be applied on the C-BOX 3X0 left side, around the 25-pin connector, or on the C-BOX 3X0 back side. The purpose of this label is to keep the C-BOX 3X0 cover and bottom part together when the scanner is open.

  • Page 19: Mechanical Installation

    INSTALLATION MECHANICAL INSTALLATION The diagram below gives the overall dimensions of the C-BOX 3X0 and may be used for its installation. Ø3.5 0.14 3.75 5.91 4.53 inch 6.57 Figure 5 - Overall dimensions...
  • Page 20 C-BOX 300/310 C-BOX 3X0 can be installed to operate in different positions. The two screw holes inside the housing of the C-BOX 3X0 are for mechanical fixture (Figure 6). To mount the C-BOX 3X0: Open the C-BOX 3X0 by unscrewing the 4 cover screws. If necessary, using the two mounting holes inside the device as a pattern, mark the panel with an appropriate object and then drill two holes in the panel.

  • Page 21: Electrical Connections And Setup

    INSTALLATION ELECTRICAL CONNECTIONS AND SETUP The following figure shows the typical layout. PROFIBUS MASTER C-BOX 3X0 SCANNER System Cables Figure 7 – System layout A PC can be connected to the C-BOX 3X0 (and consequently to the scanner auxiliary interface) through the internal 9-pin connector. This allows monitoring of the data transmitted by the scanner or configuration through the WinHost utility (see the scanner Installation Manual for more details).

  • Page 22: Power Supply

    C-BOX 300/310 2.5.1 Power Supply Power is supplied to the C-BOX 3X0 through the pins provided on the spring clamp connector. The power switch (see Figure 8) switches the power supply ON or OFF for both the C-BOX 3X0 and the connected scanner.
  • Page 23 INSTALLATION Incorrect grounding of the C-BOX 3X0 can injure personnel and damage equipment. Make sure that the C-BOX is correctly grounded. WARNING Although the C-BOX 3X0 is protected against polarity reversal, connecting up the power feed with incorrect polarity for extended periods can damage the device.

  • Page 24: System Wiring

    C-BOX 300/310 2.5.2 System Wiring The connection and wiring procedure for C-BOX 3X0 is described as follows: Open the C-BOX 3X0 as described in paragraph 2.2. Verify that the C-BOX 3X0 power switch is off (see Figure 8). Unscrew the compression connectors and pass all the system cables through them into the C-BOX 3X0 housing.
  • Page 25 INSTALLATION The C-BOX 3X0 spring clamp connector pinouts are indicated in the following table. Refer to the scanner Installation Manual for details. Name 1, 3, 5 2, 4, 6 7, 8 EARTH GROUND 9…12, 20, 33, 34, 40 Reserved OUT1+ OUT2+ EXT TRIG+ EXT TRIG-...

  • Page 26: Chassis Grounding Jumper Settings

    C-BOX 300/310 2.5.3 Chassis Grounding Jumper Settings The scanner chassis grounding method can be selected by positioning a jumper (see Figure 11). In this way the scanner chassis can be connected to earth ground (only if pins 7 or 8 are connected to a good earth ground) or to the power supply ground signal.

  • Page 27: Connection To A Profibus Network

    INSTALLATION 2.5.5 Connection to a Profibus Network The following figure shows a Profibus layout with C-BOX 3X0 devices connected to a Profibus Master: PROFIBUS DP Master Profibus DP Profibus DP Slave node #1 Slave node #n C-BOX 3X0 Profibus DP Slave node #2 Figure 13 - Profibus connection It is recommended to use only commercially available PROFIBUS connectors for...

  • Page 28: C-Box 3X0 Configuration For Profibus Dp Slave Node

    PROFIBUS network application as described in the configurator's Help On-Line or User's Manual. Further information on PROFIBUS protocol and Flow control is provided in the C-BOX 300/310 PROFIBUS document and Help On- Line installed from the configuration diskette provided in the C-BOX package.

  • Page 29: Configuration Switch And 9-Pin Internal Connector

    INSTALLATION CONFIGURATION SWITCH AND 9-PIN INTERNAL CONNECTOR The 9-pin internal connector may have two different functions according to the position of the configuration switch. Figure 15 - Configuration switch Figure 16 - 9-pin male connector POSITION MODE Normal Operation (default): In this position, the C-BOX 3X0 is in the normal operating mode.
  • Page 30 C-BOX 300/310 POSITION MODE CFG: When the switch is in this position, the C-BOX 3X0 is in configuration mode. The communication with the scanner is interrupted and pins 2 and 3 are no longer dedicated to the scanner auxiliary interface but to the C-BOX 3X0 configuration (see table below). The system enters configuration mode and waits to be configured through WinHost (see WinHost Help On Line).

  • Page 31: Scanner Requirements

    OFF), the C-BOX 3X0 is ready to receive code strings from the scanner's RS232 main interface. Then, it converts them to the Profibus DP network. GET/TEST/SEND: Through the C-BOX 300 internal buttons and the C-BOX 310 external keypad, it is possible to communicate with the scanner to perform one of the following functions: •...

  • Page 32: Get/Test/Send Functions

    C-BOX 300/310 2.8.1 GET/TEST/SEND Functions The C-BOX 300 has three internal function buttons. In the C-BOX 310, these three buttons are available on the cover, under the display. C-BOX 300 TEST SEND C-BOX 310 The procedure to enable the GET/TEST/SEND function is the following: Press both the buttons left and right at the same time for at least one second;...
  • Page 33 Once the buttons are released in step 1, a ten-second timeout starts. If no button is pressed within this time (no function is selected), the procedure will be cancelled. The C-Box 300 warning LED (Figure 17) is turned OFF at the end of NOTE each procedure.

  • Page 34: Led Indicators

    C-BOX 300/310 2.8.2 LED Indicators LD1 LD2 Power on Warning LED Figure 17 - LED Indicators In the C-BOX 300 the Warning LED is repeated in the bottom inside. Warning Figure 18 - C-BOX 300...
  • Page 35 INSTALLATION The internal LEDs of the C-BOX 3X0 (see Figure 17) indicate the following: (red) indicates the C-BOX 3X0 is connected to the power supply POWER ON and the power switch is ON. (red) indicates a warning or error condition. It is ON when a WARNING connection procedure is in progress (the system is busy), during a GET/TEST/SEND procedure or during the Configuration Mode.

  • Page 36: Profibus Connector (9-Pin Female External Connector)

    C-BOX 300/310 PROFIBUS CONNECTOR (9-PIN FEMALE EXTERNAL CONNECTOR) To connect C-BOX 3X0 as a Profibus DP Slave, use a standard Siemens Profibus cable with a 9-pin male connector (see DIN 19245 part 1) and plug it into the 9-pin female external connector.

  • Page 37: Technical Features

    TECHNICAL FEATURES 3 TECHNICAL FEATURES C-BOX 300 C-BOX 310 ELECTRICAL FEATURES Power Supply voltage 10 to 30 Vdc Power consumption max. 2.9 W + scanner 4.7 W + scanner USER INTERFACE LED indicators Power ON, Warning, PHYSICAL FEATURES Mechanical dimensions 167 x 115 x 61 mm (6.57 x 4.53 x 2.40 in.)
  • Page 38 DATALOGIC S.p.A., Via Candini, 2 40012 - Lippo di Calderara Bologna - Italy dichiara che declares that the déclare que le bescheinigt, daß das Gerät declare que el C-BOX 3X0, active connection box e tutti i suoi modelli and all its models et tous ses modèles...
