- Page 1 INSTRUCTION MANUAL 7 GAL. INDEPENDENT SPRAYER ATTACHMENT Models: SG46, & SG52...
- Page 2 7 GAL. INDEPENDENT SPRAYER EXPLODED VIEW RIGHT SIDE...
- Page 3 7 GAL. INDEPENDENT SPRAYER EXPLODED VIEW NOTE: Parts are the same for both left & right side.
- Page 4 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS STEP 1: Disconnect the battery, ground first and then power wire. GROUND POWER NOTE: Steps 2 & 3 instructions are the same for the right and left side, if both left & right side tanks are being installed.
- Page 5 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS STEP 4: Use an exacto or utility knife and cut out the appropri- ate “Aux” opening in the panel. RIGHT SIDE PUMP LEFT SIDE PUMP STEP 5: Attach the rocker switch to the appropriate opening. RIGHT SIDE PUMP LEFT SIDE PUMP...
- Page 6 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS 7 GALLON ATTACHMENT HARNESS PART NO. - SG-7G1-2 TO PUMP SWITCH TO GROUND BLOCK TO FUSE PANEL TO PUMP PLUG...
- Page 7 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS STEP 6: • Connect the pump harness to the pump switch. • Connect the second harness if equipped with both left & right 7 gal. attachments. • Connect the orange power wire to port 3 on the fuse block. •...
- Page 8 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS STEP 7: Connect the plug on the harness to the pump on the 7 gallon tank. STEP 8: Reconnect the battery power wire first along with the pump power wire from the wiring harness, and then recon- nect the ground wire.
- Page 9 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS OPERATION STEP 1: Press the switch on the dash to power the pump “on”. STEP 2: Turn the knob on the throttle valve to adjust the spray pressure, STEP 3: Squeeze the trigger on the spray handle to spray.
- Page 10 7 GAL. INDEPENDENT SPRAYER ASSEMBLY INSTRUCTIONS MAINTENENCE • Turn the ball valve off to stop the fluid flow. • Remove the cap from the strainer to clean it.
- Page 11 NOTES...
- Page 12 MADE IN THE USA Steel Green Mfg. 824 S State Road 39 MANUAL MANUAL DESCRIPTION Lebanon, IN 46052 PART NO. REV. PART NO. (765)-481-2890 www.steelgreenmfg.com SGM-012 SG46-52 7 GALLON INDEPENDENT SPRAYER P10030-1...
