RH Baby&child PFEIFFER UPHOLSTERED CRIB Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Made in Vietnam
Distributed in the USA by:
RHBaby&Child
2900 North Macarthur Dr.
Tracy, CA 95376
USA
www.rhbabyandchild.com
Distributed in Canada by:
RH Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING: Read all
instructions before assembling this
product. KEEP INSTRUCTIONS
FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the address above.
Include the product model number, color, and a brief description of the part. Or call 1-800-762-1005.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean and soft, dry cloth.
Blot spills immediately and wipe with a clean, damp cloth. If the crib is to be stored, store in a cool, dry place and carefully package all original
hardware to protect from loss.
TOOLS NEEDED
Allen wrench (included)
NOTE: Two people are recommended for assembly.
NOTE: When inserting bolts, turn clockwise until tight. Then loosen
tighten. Use wax or soap on all bolts to facilitate assembly.
1
3
-
of a turn. After crib is completely assembled, return to each bolt and
2
4
1/10
