7.6

Min duration

Preset the minimum operating duration that the customer can
select from the menu when configuring the quick start button or
for heating/ventilation. The value for "Min duration" can be set
between 10 minutes and the "Max duration".
 "Service" symbol has been selected in the main menu.
 "Quick start" symbol is shown in the display.
Rotate the control knob in order to choose the desired symbol
X
"Min duration".
Press the control knob in order to confirm selection.
X
 The min duration is shown in the display and the min duration
"hour" is flashing.
Rotate the control knob in order to choose the desired min
X
duration "hour".
■ Press the control knob in order to confirm selection.
 The min duration is shown in the display and the min duration
"minute" is flashing.
Rotate the control knob in order to choose the desired min
X
duration "minute".
Press the control knob in order to confirm selection.
X
7.7

Max duration

Preset the maximum operating duration that the customer can
select from the menu when configuring the quick start button
or for heating/ventilation. The range for "Max duration" can be
set between value for "Min duration" and the maximum time
applicable for the selected heater.
 "Service" symbol has been selected in the main menu.
 "Quick start" symbol is shown in the display.
Rotate the control knob in order to choose the desired symbol
X
"Max duration".
Press the control knob in order to confirm selection.
X
 The max duration is shown in the display and the max duration
"hour" is flashing.
Rotate the control knob in order to choose the desired max
X
duration "hour".
Press the control knob in order to confirm selection.
X
 The max duration is shown in the display and the max duration
"minute" is flashing.
Rotate the control knob in order to choose the desired max
X
duration "minute".
Press the control knob in order to confirm selection.
X
7.8

Permanent mode

Here you can enable or block permanent operation of the heater
by the user. Permanent mode is only possible in heaters that
support this mode. If this option is selected for heaters that do not
support permanent mode, the heater determines the operating
duration when the user starts the functions heating/ventilation in
permanent mode.
 "Service" symbol has been selected in the main menu.
 "Quick start" symbol is shown in the display.
Rotate the control knob in order to choose the desired symbol
X
"Permanent mode".
Press the control knob to choose between "On" and "Off".
X
MultiControl | SmartControl
This setting is taken over without confirmation.
7.9

Ventilation

This option can be used to remove the "Ventilation" menu item
from the customer menu. This option has no effect for heaters
that do not support "ventilation".

"Service" symbol has been selected in the main menu.
 "Quick start" symbol is shown in the display.
Rotate the control knob in order to choose the desired symbol
X
"Ventilation".
Press the control knob to choose between "On" and "Off".
X
This setting is taken over without confirmation.

7.10 Temperature range

Here you can restrict the temperature range for air heaters that
the user can select from the menu when configuring the quick
start button or when heating. The minimum temperature can be
selected between 5°C and 20°C and the maximum temperature
can be selected between 20°C and 35°C. This setting has no
effect for water heaters.
 "Service" symbol has been selected in the main menu.

"Quick start" symbol is shown in the display.
Rotate the control knob in order to choose the desired symbol
X
"Temperature range".
 If the temperature setting function is not supported by the hea-
ter, "N/A" appears in the display and no settings can be made
here.
Press the control knob in order to confirm selection.
X
 The minimum temperature is shown in the display.
Rotate the control knob to select the desired minimum tempera-
X
ture.
Press the control knob in order to confirm selection.
X
 The maximum temperature is shown in the display.
Rotate the control knob to select the desired maximum
X
temperature.
Press the control knob in order to confirm selection.
X

7.11 Show temperature

This configures the temperature display in the status bar. If this
option is switched off, the current temperature is not shown in
the status bar. The temperature shown is always the current
temperature as reported by a connected sensor or the internal
sensor in the MultiControl/SmartControl. Following a factory reset
or after selecting a new heater, all possible sensors are queried
and the first available sensor is selected for temperature determi-
nation. The query sequence is as follows:
■ External sensor on the W-bus
■ Sensor in the heater
■ Internal sensor of the MultiControl | SmartControl
 The temperature can be displayed and hidden in the main
menu.
 "Service" symbol has been selected in the main menu.

"Quick start" symbol is shown in the display.
