Summary of Contents for Webasto Thermo Call TC3
- Page 1 Installation Instructions Thermo Call TC3...
- Page 2 Thermo Call TC3 # 24990A 965 082 AMP # 98393A # 67769A...
- Page 3 Thermo Call TC3...
- Page 4 Only genuine Webasto parts may be used. See also Webasto air and water heaters accessories catalogue. NEVER try to install or repair Webasto heating or cooling systems if you have not completed a Webasto training course, you do not have the necessary technical skills and you do not have the technical documentation, tools and equipment available to ensure that you can complete the installation and repair work properly.
-
Page 5: Table Of Contents
Thermo Call TC3 Content Installation Instructions ...................... 6 General information ......................6 Certification ........................6 Delivery scope ........................6 GSM module wiring harness ....................7 Legend ..........................7 SIM card ..........................7 Installation ........................... 8 Installing GSM module .......................8 Installing GSM antenna ...................... 8 Installing push button ......................8... -
Page 6: Installation Instructions
Installation Instructions General information Certification Delivery scope With the Thermo Call TC3, retrofitted The CE marking and the e-marking are 1 Thermo Call TC3 GSM module Webasto heaters of the Thermo Top E/C located on the adhesive label on the module. -
Page 7: Gsm Module Wiring Harness
Thermo Call TC3 GSM module wiring harness All data which may be present on the SIM card will be deleted when commissioning the The included GSM module wiring harness GSM module. Thermo Top E must be adjusted with corresponding Thermo Top C "pinning into"... -
Page 8: Installation
Thermo Call TC3 Installation Installing GSM module Installing GSM antenna Installing push button The GSM module must be installed in the The antenna must be installed on the front or The push button contained in the delivery rear window. passenger compartment. -
Page 9: Connection
Thermo Call TC3 Connection Connector assignment of GSM module Socket Function Remarks 12 - 24 V (+30) Earth = 0 Output of parking heater only for Thermo Top E/C additional analogue output, 12-24 V positive * for 2nd installed heater with analogue con-... -
Page 10: Connection Of An Alarm System Installed In The Vehicle (Option)
Y-adapter 9001505A (only required if a following commissioning: the Thermo Call TC3. To define the phone digital timer 1533 is connected after the 1234IBANK:"Entry command". The entry numbers, the following text message Thermo Call TC3) command can, for example, be Alarm. -
Page 11: Connection To Heater
Thermo Call TC3 Connection to heater Thermo Top Evo or Thermo Top E/C Thermo Top Evo or Thermo Top E/C with Thermo Top Evo or Thermo Top E/C with digital timer Telestart T91/T100 HTM Insert GSM module wiring harness: see Section "GSM module wiring harness"... -
Page 12: Final Connection And Commissioning
5 minutes until it is finally ready for operation As soon as operational readiness is achieved, program the Thermo Call TC3 and put it into operation according to the operating instructions To query the firmware version send the text message command "VERSION"... -
Page 13: Technical Data
Thermo Call TC3 Technical data Power supply 8 to 35 V DC Bias current consumption 0.005 A Current consumption during data transfer 0.040 A Max. output current 1.000 A Max. input voltage 35 V Switching voltage for inputs +5.5 V Permissible ambient temperature -40 °C to +85 °C... -
Page 14: Drawing Of Installation Location For Gsm Module In Vehicle
Thermo Call TC3 Drawing of installation location for GSM module in vehicle Note or sketch the installation location of the GSM module in the following field for possible service cases. - Page 15 In multilingual versions the German language is binding. The telephone number of each country can be found in the Webasto service center leaflet or the website of the respective Webasto representative of your country. Webasto Thermo & Comfort SE Postfach 1410...
