- Page 1 Project Name: ATI Physical Therapy Prepared For: Sam Coniglio Building Systems & Services PoolPak Model #: PCP-0800-NP-I-A2NT4651N0A4AN4S OACC Model #: NC-B-1V-AUCSM-V https://www.poolpak.com 3491 Industrial Drive York, Pennsylvania 17402 1-717-757-2648 April 9, 2021...
-
Page 2: Table Of Contents
Table of Contents Unit Summary Design and Unit Performance Unit Dimension Drawing Condenser Dimension Drawing Features Summary Installation Field Wiring Diagram Remote Operator Panel General Specification Warranty Submittal 60602.1 Page 2 of 28 Apr 9, 2021... -
Page 3: Unit Summary
Unit Summary ATI Physical Therapy PCP-0800-NP-I-A2NT4651N0A4AN4S Model 2 Ton compressor dehumidifier Unit Subseries No Pool Water Heater Unit Location Indoor Cabinet Compact (Small) Supply Voltage 208V/1PH Unit Control CommandPak c/w Remote Panel Refrigerant R410A Disconnect No Disconnect Outdoor Air Duct Collar c/w Manual Damper & Filter... -
Page 4: Design And Unit Performance
Design and Unit Performance ATI Physical Therapy PCP-0800-NP-I-A2NT4651N0A4AN4S Design Data Outdoor Air (CFM) 0.5 inches Room Conditions (°FDB/%RH) 86/60 Unit Total Airflow (CFM) Electrical Data Unit Voltage (V/Ph/Hz) 208V/1PH/60 Unit Full Load Amps - FLA (A) 17.0 Unit MCA (A) (min circuit ampacity) - Page 5 Design and Unit Performance Evaporator Coil Sensible Capacity (MBH) 15.0 Total Capacity (MBH) 28.1 Latent Capacity (Lbs/h) 11.9 Circuits Condensate Drain Connection 1.0 Male NPT Reheat Coil Total Heat Rejection (MBH) 35.1 Remote Outdoor Air-Cooled Condenser Model NC-B-1V Design Air On Temp (°F) 95 F Estimated Field Charge (lbs R410A) Recommended line set size HG (in OD)
-
Page 6: Unit Dimension Drawing
CAD FILE CAD FILE PPS0S-F4HCO-F5TCO-F3LDP-0-0-0-SRI0 DATE DATE 2018-06-01 E.Hatin DRAWN BY DRAWN BY 1 of 2 SHEET SHEET 46.25 DESCRIPTION DESCRIPTION Cab S 17.5 19.75 * Refer To Unit Summary Sheet For Options Selected. Unit operating Weight: 400 LBS. 8.75 32.25 7.75 6.75... - Page 7 CAD FILE CAD FILE PPS0S-F4HCO-F5TCO-F3LDP-0-0-0-SRI0 DATE DATE 2018-06-01 E.Hatin DRAWN BY DRAWN BY 2 of 2 SHEET SHEET DESCRIPTION DESCRIPTION Cab S Supply Air Outdoor Return Air Supply Air *SA Collar Return Air Compressor Door Electrical Door *OA Damper Blower door Removable Legs Drain Pipe Connection (P-Trap Required)
-
Page 8: Condenser Dimension Drawing
CAD FILE NC-B-1V rev03 Noise l e vel at 10' (may vary due to installation): DATE Low speed, 40 dBA 01/07/19 High speed, 50 dBA DRAWN BY SHEET dslater 1 OF 1 DESCRIPTION NC-B VERTICAL AIR FLOW, 1 CIRCUIT 30 1/2 33 1/4 36 5/8 Non-Fused Disconnect... -
Page 9: Features Summary
Features Summary VIRTUAL-TECH TECHNOLOGY – REMOTE INTERNET CONTROL, DIAGNOSTICS ® AND REPORTING There’s only one way we could provide superb, factory-engineered performance after a dehumidifier leaves our plant. It’s called Virtual-Tech Technology. Virtual-Tech Technology provides a powerful array of capabilities designed to ensure peak operating performance, a minimum of down time and the absolute lowest cost of ownership in the industry. - Page 10 • Optional remote operator panel unit can be located up to 1,000 ft. away from unit • Allows live 24-7 monitoring, performance logging, computer analysis, and secure remote control via the Internet or smart phone with PoolPak’s Virtual-Tech Technology CommandPak Specifications ®...
- Page 11 No airflow, Blower overload, Firestat, High supply air temperature INDUSTRY LEADING FEATURES PoolPak dehumidifiers match or exceed the specifications of every other competitor in the marketplace. Built-in Refrigerant Pressure Transducers • Allow 24-7 Monitoring of critical suction and discharge pressures to ensure optimal system...
-
Page 12: Installation
Improper lifting procedure! Test lift the unit 24 inches to verify proper operation of lifting equipment and positioning of lift points such that the unit is level. Failure to properly lift the unit could result in equipment damage, serious injury or death. PoolPak is not responsible for the improper use of ®... - Page 13 If the condenser is installed above the dehumidifier, ensure the hot gas line has proper oil traps. Contact PoolPak if the condenser is installed more than eight (8) feet below the dehumidifier. The installer must endeavor to ensure that all industry standards for refrigeration component installation are met.
- Page 14 • Do not exceed 50’ total line length or install the condenser more than 8’ below the unit. Consult PoolPak before installing the outdoor air-cooled condenser more then 8 feet below or more than 50 feet away from the dehumidifier.
- Page 15 Installation Figure 3. Typical Outdoor Condenser Installation Charging of Remote Condensers Once a proper evacuation has been accomplished the system is ready for charging. The outdoor air- cooled condenser requires a field charge by the installing contractor. The field charge required depends on the size of the condenser and the length of the piping.
-
Page 16: Field Wiring Diagram
DRAWING NUMBER COMMENTS DATE APPROVED FWD-PCP-Z-00 FILE: PoolPak-FWD-PCP-Z-00 DFTN DATE REV #: 0.0 bsimpson 04/27/18 SHEET 1 OF 1 PCP Series Field Wiring Diagram with NC-Z/NC-B/NG-Z Remote Condenser DEHUMIDIFICATION UNIT L1 MAIN 10 ... 6 ... 1 HEAT RECOVERY PUMP ON/OFF... -
Page 17: Remote Operator Panel
The CPCS touch display replaces the LCD display with discrete buttons as the local and remote operator panels on PoolPak’s dehumidification systems. It uses the same communication interface as the previous operator panel and communicates over a RS-485 serial port. The touch display is modeled after the... - Page 18 Remote Operator Panel CommandPak Control System Touch Display ® All dimensions are in inches. Submittal 60602.1 Page 18 of 28 Apr 9, 2021...
-
Page 19: General Specification
General Specification Part 1 - General Scope Furnish and install, where indicated, a factory-assembled, fully-enclosed, split environmental control system with energy recovery feature(s) designed for natatorium environment control Features shall include: Dehumidification by means of a direct expansion evaporator coil Cooling mode with heat rejection to a remote outdoor air cooled condenser Integral minimum outdoor air connection Quality and Safety Assurance... - Page 20 General Specification Part 2 - Product General The natatorium control system shall include: Mechanical process dehumidification Indoor cabinet configuration Split system with remote outdoor air-cooled condenser for AC heat rejection Air filtration via MERV-8 2-inch pleated panel filters for return and outdoor air Minimum outdoor air connection Programmable microprocessor controller with remote Internet logging and parameter adjustment Remote operator panel(s)
- Page 21 General Specification Cabinet Construction: All cabinet 16, 20 and 24 gauge sheet metal shall be galvanized G90 steel or GalvalumeTM alloy with mill-applied zinc phosphate primer followed by an exterior grade white silicone modified polyester top coat. The sheet metal is engineered to form a cabinet with maximum strength and rigidity. All seams shall be caulked with silicone to prevent air and water leakage or infiltration The cabinet walls shall be of single-wall construction using 20 gauge pre-painted steel with 1 inch of fiberglass insulation protected by an anti-microbial top coat...
- Page 22 General Specification Coil shall have galvanized casing and end plates Aluminum fin and copper tube joints mechanically bonded to assure high heat transfer Coils shall have a 3-year warranty extension for a total of 5 years coverage Drain Pans Each evaporator coil shall be provided with a positive draining, compound-sloped, baked powder paint coated aluminum drain pan with fully-welded corners to ensure zero water retention.
- Page 23 General Specification Blower motors shall be protected with thermal trip overloads The system shall have a voltage monitor with phase protection Available dry contacts shall include: Alarm Blower interlock Stage 1 & 2 heating Outdoor air damper control Remote exhaust fan #1 Remote exhaust fan #2 Outdoor-air cooled equipment System on...
- Page 24 General Specification Space relative humidity The following sensors shall be unit-mounted and monitored at the operator panel. All information from these items shall be actively used in the system control and operation strategies: Refrigerant high pressure Refrigerant low pressure Return air temperature Supply air temperature Return air relative humidity Evaporator leaving air temperature...
- Page 25 General Specification Part 3 - Execution Product Delivery, Acceptance, Storage and Handling Perform a thorough physical inspection of the system upon delivery from the shipment carrier Identify and immediately report any physical damage to manufacturer If the system is to be stored prior to installation, store in a clean, dry place protected from weather, dirt, fumes, water, construction and physical damage Handle the system carefully during installation to prevent damage Damaged systems or components shall not be installed.
-
Page 26: Warranty
Replacement Part Warranty If a replacement part provided by PoolPak under this warranty fails due to a material defect prior to the end of the Two-Year Parts Warranty (or the end of the extended warranty period if applicable), whichever comes first, PoolPak will provide a new or rebuilt part F.O.B. - Page 27 DASV's Customer Support team. PoolPak will not be responsible for refrigerant lost from the system due to improperly installed contractor piping to the remote outdoor air-cooled condenser.
- Page 28 2. Optional Five-Year Dehumidifier Coil Warranty Subject to the terms above, PoolPak will provide a replacement coil for up to 60 months from the date of the warranty activation. Extended coil warranties are for parts of the dehumidifier only and does not cover parts of dry cooler or OACC coils.
