- Page 1 Project Name: Manchester Hilton Prepared For: Stephan Becker Trumbull Campbell Associates, Inc. PoolPak Model #: PCP-1800-VN-I-A2NT1252W2A2AN0S OACC Model #: NC-Z-1V-AUCSM-V https://www.poolpak.com 3491 Industrial Drive York, Pennsylvania 17402 1-717-757-2648 April 20, 2021...
-
Page 2: Table Of Contents
Table of Contents Unit Summary Design and Unit Performance Unit Dimension Drawing Condenser Dimension Drawing Features Summary Installation Field Wiring Diagram Pool Water Piping General Specification Warranty Hot Water Valve Submittal 60169.5 Page 2 of 32 Apr 20, 2021... -
Page 3: Unit Summary
Unit Summary Manchester Hilton PCP-1800-VN-I-A2NT1252W2A2AN0S Model 5 Ton compressor dehumidifier Unit Subseries Pool Water Heater, Vented Unit Location Indoor Cabinet Vertical - Single Walled - Mirrored Supply Voltage 208V/1PH Unit Control CommandPak Refrigerant R410A Disconnect No Disconnect Outdoor Air Duct Collar c/w Manual Damper & Filter... -
Page 4: Design And Unit Performance
Design and Unit Performance Manchester Hilton PCP-1800-VN-I-A2NT1252W2A2AN0S Design Data Outdoor Air (CFM) 0.5 inches Room Conditions (°FDB/%RH) 82/58 Unit Total Airflow (CFM) 2500 Electrical Data Unit Voltage (V/Ph/Hz) 208V/1PH/60 Unit Full Load Amps - FLA (A) 35.9 Unit MCA (A) (min circuit ampacity) - Page 5 Design and Unit Performance Evaporator Coil Sensible Capacity (MBH) 38.5 Total Capacity (MBH) 67.5 Latent Capacity (Lbs/h) 25.9 Circuits Condensate Drain Connection 1.0 Male NPT Reheat Coil Total Heat Rejection (MBH) 84.4 Pool Heating Type Cupro-nickel Co-axial Vented Capacity (MBH) Water Flow Rate (GPM) Water Pressure Drop (PSI) Connection Size (in)
- Page 6 Design and Unit Performance Auxiliary Heat Location Unit Mounted Type Hot Water Coil Capacity (MBH) Entering/Leaving Fluid Temp (°F) 180/160 Entering/Leaving Air Temp (°F) 82/117.4 Unit Fluid Flow Rate (GPM) Fluid Pressure Drop (ft) Valve Pressure Drop (ft) Total Pressure Drop (ft) Connection Size (in ID) Connection Type Stub...
-
Page 7: Unit Dimension Drawing
CAD FILE CAD FILE PPRV0M-F1HCO-F2TCO-E9TDP-0-0-0-SHI0 DATE DATE 2018-05-18 DRAWN BY DRAWN BY SHEET SHEET E.Hatin 1 of 2 DESCRIPTION DESCRIPTION Cab RV mirror * Refer To Unit Summary Sheet For Options Selected. 6.75 Unit operating Weight: 810 Lbs. 18" Clearance For Service 21.75 1.75 4.25... - Page 8 CAD FILE CAD FILE PPRV0M-F1HCO-F2TCO-E9TDP-0-0-0-SHI0 *SA collar DATE DATE 2018-05-18 DRAWN BY DRAWN BY SHEET SHEET E.Hatin 2 of 2 *OA Damper DESCRIPTION DESCRIPTION Cab RV mirror Return Air Compressor and Electrical Access *Air Cooled A/C connections Outside Air Supply Air *Water Cooled A/C connections Return Air Return Air...
-
Page 9: Condenser Dimension Drawing
CAD FILE NC-Z-1V rev03 Noise l e vel at 10' (may vary due to installation): DATE Low speed, 40 dBA 01/07/19 High speed, 60 dBA DRAWN BY SHEET dslater 1 OF 1 DESCRIPTION NC-Z VERTICAL AIR FLOW, 1 CIRCUIT Liquid Connection 5/8"... -
Page 10: Features Summary
Features Summary VIRTUAL-TECH TECHNOLOGY – REMOTE INTERNET CONTROL, DIAGNOSTICS ® AND REPORTING There’s only one way we could provide superb, factory-engineered performance after a dehumidifier leaves our plant. It’s called Virtual-Tech Technology. Virtual-Tech Technology provides a powerful array of capabilities designed to ensure peak operating performance, a minimum of down time and the absolute lowest cost of ownership in the industry. - Page 11 • Optional remote operator panel unit can be located up to 1,000 ft. away from unit • Allows live 24-7 monitoring, performance logging, computer analysis, and secure remote control via the Internet or smart phone with PoolPak’s Virtual-Tech Technology CommandPak Specifications ®...
- Page 12 No airflow, Blower overload, Firestat, High supply air temperature INDUSTRY LEADING FEATURES PoolPak dehumidifiers match or exceed the specifications of every other competitor in the marketplace. Built-in Refrigerant Pressure Transducers • Allow 24-7 Monitoring of critical suction and discharge pressures to ensure optimal system...
-
Page 13: Duct Connections
Improper lifting procedure! Test lift the unit 24 inches to verify proper operation of lifting equipment and positioning of lift points such that the unit is level. Failure to properly lift the unit could result in equipment damage, serious injury or death. PoolPak is not responsible for the improper use of ®... - Page 14 If the condenser is installed above the dehumidifier, ensure the hot gas line has proper oil traps. Contact PoolPak if the condenser is installed more than eight (8) feet below the dehumidifier. The installer must endeavor to ensure that all industry standards for refrigeration component installation are met.
- Page 15 • Do not exceed 50’ total line length or install the condenser more than 8’ below the unit. Consult PoolPak before installing the outdoor air-cooled condenser more then 8 feet below or more than 50 feet away from the dehumidifier.
- Page 16 Installation Figure 3. Typical Outdoor Condenser Installation Charging of Remote Condensers Once a proper evacuation has been accomplished the system is ready for charging. The outdoor air- cooled condenser requires a field charge by the installing contractor. The field charge required depends on the size of the condenser and the length of the piping.
-
Page 17: Field Wiring Diagram
DRAWING NUMBER COMMENTS DATE APPROVED FWD-PCP-Z-00 FILE: PoolPak-FWD-PCP-Z-00 DFTN DATE REV #: 0.0 bsimpson 04/27/18 SHEET 1 OF 1 PCP Series Field Wiring Diagram with NC-Z/NC-B/NG-Z Remote Condenser DEHUMIDIFICATION UNIT L1 MAIN 10 ... 6 ... 1 HEAT RECOVERY PUMP ON/OFF... -
Page 18: Pool Water Piping
DEHUMIDIFIER BALL VALVE BALL VALVE AUXILIARY PUMP BALL VALVE FLOW METER DEHUMIDIFIER BALL VALVE CERTAIN MODELS FLOW METER CHECK VALVE BALL VALVE (BY PASS) BALL VALVE BALL VALVE AUT. POOL AUX. POOL CHEMICAL FILTER HEATER FEEDER BALL VALVE POOL BALL VALVE NOTES: ---*-Components are optional ---This drawing is to be used as referrence only... -
Page 19: General Specification
General Specification Part 1 - General Scope Furnish and install, where indicated, a factory-assembled, fully-enclosed, split environmental control system with energy recovery feature(s) designed for natatorium environment control Features shall include: Dehumidification by means of a direct expansion evaporator coil Space heating by means of a packaged hot water coil Cooling mode with heat rejection to a remote outdoor air cooled condenser Pool water heating from reclaimed compressor waste heat by means of a vented heat exchanger... - Page 20 General Specification Part 2 - Product General The natatorium control system shall include: Mechanical process dehumidification Indoor cabinet configuration Single wall cabinet configuration for use in conditioned/ventilated mechanical spaces only Split system with remote outdoor air-cooled condenser for AC heat rejection A packaged hot water heating coil, sized as specified by the design engineer to meet the skin losses and outdoor air heating loads Potable water rated coaxial condensing heat exchanger(s) with double wall vented construction for pool water heating using...
- Page 21 General Specification The return pool water temperature is below the pool water setpoint If the compressor is already operating due to a Dehumidification or Air Conditioning demand, the control valves will divert the compressor hot gas through the coaxial heat exchanger to heat the pool water, with the remainder rejected at the air reheat coil or the AC heat exchanger If there is no pre-existing demand for the compressor to operate, the microprocessor sends a signal to the auxiliary pool water heater (remote by others) to operate.
- Page 22 General Specification the airflow within the dehumidifier during electrical servicing. All electrical components shall be mounted on a 16 gauge galvanized sub-panel Filters Wherever possible, air filters shall be standard sized, replaceable, off-the-shelf filters including: Return Air: 2-Inch MERV 8, 30% pleated filters with rust-free non-metallic structure on a slide in rack Outside Air: 2-Inch MERV 8, 30% pleated filters with rust-free non-metallic structure Coils Evaporator/dehumidifier coils shall be designed for maximum moisture removal capacity...
- Page 23 General Specification The compressor(s) shall be mounted on rubber-in-shear isolators to limit the transmission of noise and vibration The compressor(s) shall be equipped with removable crankcase heater(s) for liquid migration protection The compressor(s) shall be located outside the conditioned air stream in the system's service vestibule The compressor manufacturer must have a wholesale outlet for replacement parts in the nearest major city Refrigeration Circuit The system shall consist of one refrigeration circuit for dehumidification and sensible cooling...
- Page 24 General Specification A microprocessor controller with the following characteristics will be provided: All set points and parameter adjustments are pre-programmed at the factory during quality control testing The microprocessor program shall be stored on updatable FLASH memory A minimum of 11 analogue inputs, 4 analogue outputs, 24 digital inputs and 16 digital outputs Four serial interface ports including both RS232 and RS485 types An Ethernet port with RJ-45 connector and LED activity indicator A real time clock to time-stamp the system operation log and to enable a programmable 7-day occupation schedule...
- Page 25 General Specification System off Anti-short cycle delay Auxiliary Air Heating The packaged hot water coil shall be sized to meet the scheduled heating capacity and have the following characteristics: Modulating (0-10V) auxiliary air heat control by means of a factory mounted and wired three-way control valve Auxiliary air heating coil tubes, fins, headers, casing and end-plates shall be fully protected by a polyester/enamel coating for maximum corrosion protection.
- Page 26 General Specification Part 3 - Execution Product Delivery, Acceptance, Storage and Handling Perform a thorough physical inspection of the system upon delivery from the shipment carrier Identify and immediately report any physical damage to manufacturer If the system is to be stored prior to installation, store in a clean, dry place protected from weather, dirt, fumes, water, construction and physical damage Handle the system carefully during installation to prevent damage Damaged systems or components shall not be installed.
-
Page 27: Warranty
Replacement Part Warranty If a replacement part provided by PoolPak under this warranty fails due to a material defect prior to the end of the Two-Year Parts Warranty (or the end of the extended warranty period if applicable), whichever comes first, PoolPak will provide a new or rebuilt part F.O.B. - Page 28 DASV's Customer Support team. PoolPak will not be responsible for refrigerant lost from the system due to improperly installed contractor piping to the remote outdoor air-cooled condenser.
- Page 29 2. Optional Five-Year Dehumidifier Coil Warranty Subject to the terms above, PoolPak will provide a replacement coil for up to 60 months from the date of the warranty activation. Extended coil warranties are for parts of the dehumidifier only and does not cover parts of dry cooler or OACC coils.
-
Page 30: Repair Information
Code No. LIT-1900229 Issued March 2017 VG1000 Series Three-Way, Plated Brass Trim, NPT End Connections Ball Valves with Non-Spring Return Electric Actuators Catalog Page Description • Graphite-Reinforced Polytetrafluoroethylene (PTFE) Seats — VG1000 Series Ball Valves are designed to include 15% graphite-reinforced ball seals, regulate the flow of hot or chilled water and, for providing better wear resistance. - Page 31 VG1000 Series Three-Way, Plated Brass Trim, NPT End Connections Ball Valves with Non-Spring Return Electric Actuators Catalog Page (Continued) Three-Way Plated Brass Trim Ball Valves, Non-Spring Return, VA9300 Series Electric Actuators without Switches Fluid Temperature: AC/DC 24 V 23 to 203°F (-5 to 95°C) On/Off Floating DC 0(2) to 10 V...
-
Page 32: Technical Specifications
VG1000 Series Three-Way, Plated Brass Trim, NPT End Connections Ball Valves with Non-Spring Return Electric Actuators Catalog Page (Continued) Technical Specifications VG1000 Series Three-Way, Plated Brass Trim, NPT End Connections Ball Valves with Non-Spring Return Electric Actuators Hot Water, Chilled Water, and 50/50 Glycol Solutions for HVAC Systems Service Valve Fluid Temperature Limits Water...
