- Page 1 Project Name: Best Western - Hershey PA Prepared For: Lisa Goodyear Engineered Building Systems (York/New Cumberland) PoolPak Model #: PCP-1400-NV-I-A2NT1202N0C2AN0 OACC Model #: NC-B-1V-CUCSM-V https://www.poolpak.com 3491 Industrial Drive York, Pennsylvania 17402 1-717-757-2648 December 9, 2020...
-
Page 2: Table Of Contents
Table of Contents Unit Summary Design and Unit Performance Unit Dimension Drawing Condenser Dimension Drawing Features Summary Installation Field Wiring Diagram General Specification Warranty Factory Assisted Start-Up Submittal 53175.3 Page 2 of 28 Dec 9, 2020... -
Page 3: Unit Summary
Unit Summary Best Western - Hershey PA PCP-1400-NV-I-A2NT1202N0C2AN0 Model 4 Ton compressor dehumidifier Unit Subseries No Pool Water Heater Unit Location Indoor Cabinet Vertical - Single Walled - Standard Supply Voltage 208V/3PH Unit Control CommandPak Refrigerant R410A Disconnect No Disconnect Outdoor Air Duct Collar c/w Manual Damper &... -
Page 4: Design And Unit Performance
Design and Unit Performance Best Western - Hershey PA PCP-1400-NV-I-A2NT1202N0C2AN0 Design Data Outdoor Air (CFM) 0.5 inches Room Conditions (°FDB/%RH) 84/60 Unit Total Airflow (CFM) 2000 Electrical Data Unit Voltage (V/Ph/Hz) 208V/3PH/60 Unit Full Load Amps - FLA (A) 22.6... - Page 5 Design and Unit Performance Evaporator Coil Sensible Capacity (MBH) 31.4 Total Capacity (MBH) 57.6 Latent Capacity (Lbs/h) 23.5 Circuits Reheat Coil Total Heat Rejection (MBH) 72.0 Remote Outdoor Air-Cooled Condenser Model NC-B-1V Design Air On Temp (°F) 95 F Estimated Field Charge (lbs R410A) Recommended line set size HG (in OD) Recommended line set size LQ (in OD) Maximum line length (ft)
-
Page 6: Unit Dimension Drawing
CAD FILE CAD FILE PPRV0S-F1HCO-F2TCO-E9TDP-0-0-0-SHI0 DATE DATE 2018-05-04 DRAWN BY DRAWN BY SHEET SHEET E.Hatin 1 of 2 DESCRIPTION DESCRIPTION Cab RV * Refer To Unit Summary Sheet For Options Selected. Unit Operating Weight: 860 Lbs 6.75 18" Min. Access For Coil Removal 1.75 21.75... - Page 7 CAD FILE CAD FILE PPRV0S-F1HCO-F2TCO-E9TDP-0-0-0-SHI0 DATE DATE 2018-05-04 *S.A. collar DRAWN BY DRAWN BY SHEET SHEET E.Hatin 2 of 2 *OA Damper DESCRIPTION DESCRIPTION Cab RV Return Air Compressor and Electrical Access Outdoor Supply Air *Water Cooled A/C Connection *Air Cooled A/C Connection *Hot Water Pipe Connection *Pool Connection Return Air...
-
Page 8: Condenser Dimension Drawing
CAD FILE NC-B-1V rev03 Noise l e vel at 10' (may vary due to installation): DATE Low speed, 40 dBA 01/07/19 High speed, 50 dBA DRAWN BY SHEET dslater 1 OF 1 DESCRIPTION NC-B VERTICAL AIR FLOW, 1 CIRCUIT 30 1/2 33 1/4 36 5/8 Non-Fused Disconnect... -
Page 9: Features Summary
Features Summary VIRTUAL-TECH TECHNOLOGY – REMOTE INTERNET CONTROL, DIAGNOSTICS ® AND REPORTING There’s only one way we could provide superb, factory-engineered performance after a dehumidifier leaves our plant. It’s called Virtual-Tech Technology. Virtual-Tech Technology provides a powerful array of capabilities designed to ensure peak operating performance, a minimum of down time and the absolute lowest cost of ownership in the industry. - Page 10 • Optional remote operator panel unit can be located up to 1,000 ft. away from unit • Allows live 24-7 monitoring, performance logging, computer analysis, and secure remote control via the Internet or smart phone with PoolPak’s Virtual-Tech Technology CommandPak Specifications ®...
- Page 11 No airflow, Blower overload, Firestat, High supply air temperature INDUSTRY LEADING FEATURES PoolPak dehumidifiers match or exceed the specifications of every other competitor in the marketplace. Built-in Refrigerant Pressure Transducers • Allow 24-7 Monitoring of critical suction and discharge pressures to ensure optimal system...
-
Page 12: Duct Connections
Improper lifting procedure! Test lift the unit 24 inches to verify proper operation of lifting equipment and positioning of lift points such that the unit is level. Failure to properly lift the unit could result in equipment damage, serious injury or death. PoolPak is not responsible for the improper use of ®... - Page 13 If the condenser is installed above the dehumidifier, ensure the hot gas line has proper oil traps. Contact PoolPak if the condenser is installed more than eight (8) feet below the dehumidifier. The installer must endeavor to ensure that all industry standards for refrigeration component installation are met.
- Page 14 • Do not exceed 50’ total line length or install the condenser more than 8’ below the unit. Consult PoolPak before installing the outdoor air-cooled condenser more then 8 feet below or more than 50 feet away from the dehumidifier.
- Page 15 Installation Figure 3. Typical Outdoor Condenser Installation Charging of Remote Condensers Once a proper evacuation has been accomplished the system is ready for charging. The outdoor air- cooled condenser requires a field charge by the installing contractor. The field charge required depends on the size of the condenser and the length of the piping.
-
Page 16: Field Wiring Diagram
DRAWING NUMBER COMMENTS DATE APPROVED FWD-PCP-Z-00 FILE: PoolPak-FWD-PCP-Z-00 DFTN DATE REV #: 0.0 bsimpson 04/27/18 SHEET 1 OF 1 PCP Series Field Wiring Diagram with NC-Z/NC-B/NG-Z Remote Condenser DEHUMIDIFICATION UNIT L1 MAIN 10 ... 6 ... 1 HEAT RECOVERY PUMP ON/OFF... -
Page 17: General Specification
General Specification Part 1 - General Scope Furnish and install, where indicated, a factory-assembled, fully-enclosed, split environmental control system with energy recovery feature(s) designed for natatorium environment control Features shall include: Dehumidification by means of a direct expansion evaporator coil Cooling mode with heat rejection to a remote outdoor air cooled condenser Integral minimum outdoor air connection Quality and Safety Assurance... - Page 18 General Specification Part 2 - Product General The natatorium control system shall include: Mechanical process dehumidification Indoor cabinet configuration Single wall cabinet configuration for use in conditioned/ventilated mechanical spaces only Split system with remote outdoor air-cooled condenser for AC heat rejection Air filtration via MERV-8 2-inch pleated panel filters for return and outdoor air Minimum outdoor air connection Programmable microprocessor controller with remote Internet logging and parameter adjustment...
- Page 19 General Specification Cabinet Cabinet Construction: All cabinet 16, 20 and 24 gauge sheet metal shall be galvanized G90 steel or GalvalumeTM alloy with mill-applied zinc phosphate primer followed by an exterior grade white silicone modified polyester top coat. The sheet metal is engineered to form a cabinet with maximum strength and rigidity.
- Page 20 General Specification Aluminum fin and copper tubes mechanically bonded to assure high heat transfer. Air reheat condenser coils shall be sized for variable heat transfer into the air with a capacity of 100% of the compressors total required heat of rejection. Coils shall be fully dipped and coated with a polyester/enamel coating for maximum corrosion protection.
- Page 21 General Specification The system shall have an externally adjustable balanced port design mechanical thermostatic expansion valve. The valve shall have a removable power head Tamper proof, hermetically sealed non-adjustable high and low pressure switches and refrigeration service valves shall be installed using Schrader type valves.
- Page 22 General Specification The following status LEDs shall be on the controller: Alarm - indicates there has been a failure requiring service. Dehumidification - indicates that the system is dehumidifying the space. Cooling - indicates that the air-conditioning mode. Space Heat - indicates that the space heating is operating. Maintenance - indicates whether or not maintenance is required.
- Page 23 General Specification The fan assembly shall be balanced in Class G 6.3 acc DIN ISO 1940, dynamic on two levels The fan assembly shall be suitable for ambient temperatures of -40°C to max. +70°C Thermal contacts installed in the windings compliant with THCL 155 Drive motor in external rotor principle, sealed in protection class IP54 with moisture protection impregnation of the windings, topical protection High corrosion resistance design with high quality and reliability...
- Page 24 General Specification Part 3 - Execution Product Delivery, Acceptance, Storage and Handling Perform a thorough physical inspection of the system upon delivery from the shipment carrier Identify and immediately report any physical damage to manufacturer If the system is to be stored prior to installation, store in a clean, dry place protected from weather, dirt, fumes, water, construction and physical damage Handle the system carefully during installation to prevent damage Damaged systems or components shall not be installed.
-
Page 25: Warranty
Replacement Part Warranty If a replacement part provided by PoolPak under this warranty fails due to a material defect prior to the end of the Two-Year Parts Warranty (or the end of the extended warranty period if applicable), whichever comes first, PoolPak will provide a new or rebuilt part F.O.B. - Page 26 DASV's Customer Support team. PoolPak will not be responsible for refrigerant lost from the system due to improperly installed contractor piping to the remote outdoor air-cooled condenser.
- Page 27 2. Optional Five-Year Dehumidifier Coil Warranty Subject to the terms above, PoolPak will provide a replacement coil for up to 60 months from the date of the warranty activation. Extended coil warranties are for parts of the dehumidifier only and does not cover parts of dry cooler or OACC coils.
-
Page 28: Factory Assisted Start-Up
Factory Assisted Start-Up FACTORY ASSISTED START-UP The Manufacturer’s Factory technical service representative will be present on-site during the start-up for one visit only to assist the installing contractor. The representative will apply his extensive knowledge of the equipment to ensure a proper start-up and assist in making the necessary adjustments to achieve optimal operation.
