- Page 1 With length measuring function Thin Long Stroke Hand LSTM-HP2 Series INSTRUCTION MANUAL SM-A46867-A • Read this Instruction Manual before using the product. • Read the safety notes carefully. • Keep this Instruction Manual in a safe and convenient place for future reference.
-
Page 2: Preface
• Since there are a wide variety of customer applications, it is impossible for CKD to be aware of all of them. Depending on the application or usage, the product may not be able to exercise its full performance or an accident may occur due to fluid, piping, or other conditions. -
Page 3: Safety Information
SM-A46867-A SAFETY INFORMATION SAFETY INFORMATION When designing and manufacturing any device incorporating the product, the manufacturer has an obligation to ensure that the device is safe. To that end, make sure that the safety of the machine mechanism of the device, the fluid control circuit, and the electric system that controls such mechanism is ensured. -
Page 4: Precautions On Product Use
• For applications where life or properties may be adversely affected and special safety measures are required. (Exception is made if the customer consults with CKD prior to use and understands the specifications of the product. However, even in that case, safety measures must be taken to avoid danger in case of a possible failure.) -
Page 5: Precautions On Product Disposal
SM-A46867-A SAFETY INFORMATION Precautions on Product Disposal CAUTION When disposing of the product, comply with laws pertaining to disposal and cleaning of wastes and have an industrial waste disposal company dispose of the product. 2021-03-29... -
Page 6: Table Of Contents
Precautions on Design and Selection ................iii Precautions on Product Disposal .................. iv CONTENTS ........................v PRODUCT OVERVIEW ..................... 1 Model Number Indication ..................1 1.1.1 LSTM-HP2 Series ..................1 Specifications ...................... 2 1.2.1 Product specifications ..................2 INSTALLATION ......................3 Environment ......................3 Unpacking ...................... -
Page 7: Product Overview
SM-A46867-A 1. PRODUCT OVERVIEW 1. PRODUCT OVERVIEW 1.1 Model Number Indication 1.1.1 LSTM-HP2 Series ◼ Example of model number indication 2021-03-29... -
Page 8: Specifications
SM-A46867-A 1. PRODUCT OVERVIEW 1.2 Specifications 1.2.1 Product specifications LSTM-HP2 Descriptions LSTM-12 LSTM-16 LSTM-20 φ12×2 φ16×2 φ20×2 Bore size Double acting Actuation Compressed air Working fluid Max. working pressure Min. working pressure Port size Operating stroke length Power supply 24 VDC ±10% voltage Current 25 mA or less... -
Page 9: Installation
SM-A46867-A 2. INSTALLATION 2. INSTALLATION 2.1 Environment CAUTION When using the product in a cutting, casting, or welding plant, install a cover to prevent foreign matters such as cutting fluid, chips, powder, and dust from entering. Do not use the equipment in the following environments. •... -
Page 10: Unpacking
SM-A46867-A 2. INSTALLATION 2.2 Unpacking • Check that the model number ordered and the model number indicated on the product are the same. • Check the exterior of the product for any damage. • When storing the product, take proper measures to prevent foreign matters from entering the cylinder. -
Page 11: Tightening Torque
SM-A46867-A 2. INSTALLATION ◼ Tightening Torque When mounting the product where vibrations may occur, take measures (such as installing a spring washer or applying an adhesive) to prevent the bolt from loosening. ●Top mounting Model Bolt size Tightening torque (N·m) Max. -
Page 12: Allowable Load
SM-A46867-A 2. INSTALLATION ●Bottom mounting Model Bolt size Tightening torque (N·m) Max. screw-in depth LSTM-12 M4×0.7 LSTM-16 M5×0.8 LSTM-20 M6×1.0 ●Using through holes Model Bolt size Tightening torque (N·m) LSTM-12 M3×0.5 0.88 LSTM-16 M4×0.7 LSTM-20 M5×0.8 ◼ Allowable load For details, refer to the "Model selection" pages in the catalog. 2021-03-29... -
Page 13: Finger
SM-A46867-A 2. INSTALLATION 2.3.2 Finger ◼ Rigidity of the attachment If the attachment is not rigid enough, sagging can result and cause the finger to twist or adversely affect operation. ◼ Mounting the attachment The effect on the hand body must be taken into consideration when mounting the attachment to the finger. -
Page 14: Piping
SM-A46867-A 2. INSTALLATION 2.4 Piping WARNING Insert the tube into the fitting until it firmly rests on the tube end and make sure that the tube does not come off before use. • Use pipes that are made of corrosion-resistant materials after the filter such as zinc-plated pipes, nylon tubes, and rubber tubes. - Page 15 SM-A46867-A 2. INSTALLATION ◼ Seal material Use a seal tape or a seal material to stop leakage from piping. Apply a seal tape or seal material to the screw threads leaving two or more threads at the pipe end uncovered or uncoated. If the pipe end is fully covered or coated, a shred of seal tape or residue of seal material may enter inside of the pipes or device and cause a failure.
-
Page 16: Wiring
SM-A46867-A 2. INSTALLATION 2.5 Wiring WARNING Use a DC stabilized power supply for the product. Do not connect noise-generating devices such as motors and valves to the power supply used for this product. CAUTION Install the wiring so that no induction noise is applied to the sensor/amplifier section. •... -
Page 17: Cable Connection
SM-A46867-A 2. INSTALLATION 2.5.1 Cable connection CAUTION Turn off the power before wiring the product. Do not touch the mating faces of the connectors with wet hands. Wipe off any moisture on the connectors and peripheral parts before wiring. Insulation failure may occur if there is moisture. -
Page 18: Internal Circuit And Plug Contact
SM-A46867-A 2. INSTALLATION 2.5.2 Internal circuit and plug contact ◼ Internal circuit (LSTM) Main circuit 主回路 Power indicator 電源表示灯(緑) (Green) Drive circuit 駆動回路 Constant Power 定電圧回路 電源＋24V voltage circuit supply +24 V 1 V to 5 V output Output Amplification 1-5V 出力... -
Page 19: Usage
SM-A46867-A 3. USAGE 3. USAGE 3.1 Using the Hand CAUTION Do not apply excessive load to the finger when attaching, removing, or transferring the workpiece. Scratches and dents may occur on the rolling surface of the finger linear guide and possibly cause a malfunction. -
Page 20: Maintenance And Inspection
SM-A46867-A 4. MAINTENANCE AND INSPECTION 4. MAINTENANCE AND INSPECTION WARNING Do not disassemble the product. Do not touch electrical wiring connections (bare live parts) of actuators equipped with solenoid valves, actuators equipped with switches, and other such actuators. Do not touch live parts with bare hands. An electric shock may occur. -
Page 21: Periodic Inspection
SM-A46867-A 4. MAINTENANCE AND INSPECTION 4.1 Periodic Inspection In order to use the product under optimum conditions, perform a periodic inspection every six months or when the operation count reaches 5 hundred thousand times. 4.1.1 Inspection item • Actuation state •... -
Page 22: Consumable Parts
SM-A46867-A 4. MAINTENANCE AND INSPECTION 4.1.4 Consumable parts LSTM-12 to 20A Section A φ12 Section B φ20 2021-03-29... - Page 23 SM-A46867-A 4. MAINTENANCE AND INSPECTION Parts list * Cannot be disassembled Part name Material Quantity Finger Stainless steel Linear guide Stainless steel Hexagon socket set screw Stainless steel Round R-type stop ring φ12 Steel φ16 to 20 C-type stop ring Steel Hexagon socket set screw Stainless steel...
-
Page 24: Troubleshooting
SM-A46867-A 5. TROUBLESHOOTING 5. TROUBLESHOOTING 5.1 Problems, Causes, and Solutions If the product does not operate properly, check the table below for a possible solution. 5.1.1 Finger (cylinder) Problem Cause Solution No pressure or insufficient pressure is applied. Secure sufficient pressure. No signal is input to directional control valve. -
Page 25: Sensor
Zero point of trimmer. analog output voltage fluctuates. Air pressure fluctuates. Keep the air pressure constant. If you have any other questions or concerns, contact your nearest CKD sales office or distributor. 2021-03-29... -
Page 26: Warranty Provisions
If the product specified herein fails for reasons attributable to CKD within the warranty period specified below, CKD will promptly provide a replacement for the faulty product or a part thereof or repair the faulty product at one of CKD’s facilities free of charge.
