- Page 1 HEAT PRESS MODEL No: DM2 INSTRUCTION MANUAL CONTACT Seatle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 HANDLING PRECAUTIONS PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DM2 Press Features and Controls PAGE 7 OPERATING INSTRUCTIONS Preparing Press Adjusting Pressure Starting Press Setting Control Panel Pressing Turning Off Press Cleaning Press Plates...
-
Page 3: Copyright Notice
INSTRUCTION MANUAL: DM2 PAGE 2 INTRODUCTION DULYTEK DM2 manual heat press is engineered and manufactured for personal use or use in re- search laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing indus- tries. Its best applications are for personal use. - Page 4 INSTRUCTION MANUAL: DM2 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
NOT attempt to use the equipment with a two-prong electrical cord or any other way without proper grounding. • Contact DULYTEK if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. -
Page 6: Item Checklist
4. Remove any protective or promotional labels from the press and other parts if applicable. 5. Examine the press and its parts for any damage. If found one, take a picture and contact DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with your CHECKLIST machine. -
Page 7: Getting Familiar
INSTRUCTION MANUAL: DM2 PAGE 6 GETTING FAMILIAR DM2 FEATURES ON/OFF Switch AND CONTROLS AC Power Socket Lever Control Panel Pressure Knob Top Platen Bottom Platen Press Base Figure A Table Clamp © 2020 Dulytek Seattle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com... - Page 8 INSTRUCTION MANUAL: DM2 PAGE 7 OPERATING INSTRUCTIONS PREPARING 1. Prepare materials you wish to press. Please see PRESSING TIPS PRESS (https://bit.ly/2YuM8pR) for more information. 2. Make sure the press stands on a flat sturdy table or countertop. 3. Optional but strongly recommended: Secure the press by fastening its base to the table surface with the included table clamp as shown on the Figure A.
- Page 9 INSTRUCTION MANUAL: DM2 PAGE 8 OPERATING INSTRUCTIONS (continued) SETTING 2. Press Up or Down buttons to select the desired temperature (Fig. CONTROL 2). The selected temperature is shown on the upper line of the display. PANEL Tip: Enter the temperature either in °F or °C; you will be able to select the (continued) temperature scale later. 3. Press SET button again (Fig. 3) to go to the temperature setting mode for the bottom platen. Fig. 4 Fig. 5 Fig.
- Page 10 INSTRUCTION MANUAL: DM2 PAGE 9 OPERATING INSTRUCTIONS (continued) SETTING 9. Press SET button once more (Fig. 9) to record all control panel’s settings. CONTROL The platens start heating, and the heating icons are now displayed on the PANEL screen (Fig. 10). (continued) Fig. 10 Fig. 11 Fig. 12 PRESSING 1. Wait until the platens heat up to the desired temperature (Fig. 11). Tip: Once heating is finished, the heating icons are turned off. 2. Place the prepared material in the center of the bottom platen 3.
-
Page 11: Technical Specifications
INSTRUCTION MANUAL: DM2 PAGE 10 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DM2-E Maximum Force 4000 lb / 2 Ton Power 360 W Current 3.27 A 1.64 A Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates Platen Size 3 x 3 in / 75 x 75 mm Platen Thickness 0.8 in / 20 mm Temperature Range up to 302 °F / 150 °C...
