- Page 1 PRESS KIT MODEL No: DHPK34 INSTRUCTION MANUAL CONTACT Seattle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Required Equipment Recommended Parts PAGE 6 GETTING FAMILIAR DHPK34 Press Kit Features and Controls PAGE 7 OPERATING INSTRUCTIONS Preparing and Starting Press Kit Setting Control Panel Pressing Turning Off Press Kit Cleaning Press Plates PAGE 11...
-
Page 3: Copyright Notice
COPYRIGHT Copyright © by DULYTEK. All rights reserved. No part of this document may be NOTICE reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written consent of the company. - Page 4 INSTRUCTION MANUAL: DHPK34 PAGE 3 SAFETY PRECAUTIONS If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
• DO NOT exceed the rated capacity. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. -
Page 6: Item Checklist
3. AC Power Cord; 4. Instruction Manual. REQUIRED The DHPK34 press kit must be used together with a standard 3 to 15 Ton EQUIPMENT hydraulic or pneumatic work shop press (up to 2.16 in / 55 mm ram diameter). RECOMMENDED... -
Page 7: Recommended Parts
INSTRUCTION MANUAL: DHPK34 PAGE 6 UNPACKING (continued) RECOMMENDED 1. Parchment paper sheets; PARTS 2. Silicone mat (optional); (continued) 3. Filter bags (optional); 4. Pre-press mold (optional); 5. Humidity packs (optional); 6. Collection tools, glass stamp, etc. Please see PRESSING TIPS (https://bit.ly/2YuM8pR) for more information. - Page 8 INSTRUCTION MANUAL: DHPK34 PAGE 7 OPERATING INSTRUCTIONS PREPARING 1. Prepare materials you wish to press. Please see PRESSING TIPS (https:// PRESS KIT bit.ly/2YuM8pR) for more information. 2. Make sure all switches and controls of the press kit are turned off. 3. Insert the AC power cord that came with the product into the controller AC...
- Page 9 INSTRUCTION MANUAL: DHPK34 PAGE 8 OPERATING INSTRUCTIONS (continued) SETTING CONTROL PANEL (continued) Fig. 1 Fig. 2 Fig. 3 3. Press SET button again (Fig. 3) to go to the temperature setting mode for the bottom platen. 4. Press Up or Down buttons to select the desired temperature (Fig.
- Page 10 INSTRUCTION MANUAL: DHPK34 PAGE 9 OPERATING INSTRUCTIONS (continued) SETTING CONTROL PANEL (continued) Fig. 7 Fig. 8 Fig. 9 The platens start heating, and the heating icons are now displayed on the screen (Fig. 10). Fig. 10 Fig. 11 Fig. 12 PRESSING 1.
- Page 11 INSTRUCTION MANUAL: DHPK34 PAGE 10 OPERATING INSTRUCTIONS (continued) PRESSING 7. Carefully release the ram pressure lifting up the shaft and the top platen (continued) 8. Remove the pressed material using heat resistant gloves or tools and exercising extreme caution. TURNING OFF 1.
-
Page 12: Technical Specifications
INSTRUCTION MANUAL: DHPK34 PAGE 11 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DHPK34 DHPK34-E Press Force 3 - 15 Ton Power 610 W Current 5.6 A 2.8 A Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates...
