- Page 1 HEAT PRESS MODEL No: DM1005 INSTRUCTION MANUAL CONTACT Dulytek Equipment help@dulytek.com © 2020 Dulytek All rights reserved Seatle, WA 98105 www.dulytek.com...
- Page 2 HANDLING PRECAUTIONS PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DM1005 Press Features and Controls PAGE 6 OPERATING INSTRUCTIONS Preparing Press Setting Pressure Starting Press Setting Control Panels Pressing Turning Off Press Cleaning Press Plates...
-
Page 3: Copyright Notice
INSTRUCTION MANUAL: DM1005 PAGE 2 INTRODUCTION DULYTEK DM1005 manual heat press is a machine engineered and manufactured for solvent-less plant rosin oil extraction for further use in research laboratories, pharmaceutical, cosmetic, food processing, and brewing industries. READ BEFORE To avoid accidents, first read SAFETY PRECAUTIONS (PAGE 2) and OPERATING HANDLING PRECAUTIONS (PAGE 4). - Page 4 INSTRUCTION MANUAL: DM1005 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
NOT attempt to use the equipment with a two-prong electrical cord or any other way without proper grounding. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. -
Page 6: Item Checklist
DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine. If anything is missing, contact DULYTEK. 1. DULYTEK DM1005 Heat Press; 2. AC Power Cord; 3. Instruction Manual. -
Page 7: Getting Familiar
INSTRUCTION MANUAL: DM1005 PAGE 6 GETTING FAMILIAR DM1005 PRESS FEATURES AND CONTROLS Pressure Knob Temperature and Timer Control Panel Press Handle ON / OFF Switch AC Power Cord Socket Top Platen Bottom Platen OPERATING INSTRUCTIONS PREPARING 1. Prepare materials you wish to press. See ROSIN PRESSING TIPS (PAGE PRESS 2. Make sure the press stands on a flat sturdy countertop. 3. Ensure the press is clean and free of residue or dust buildup. - Page 8 INSTRUCTION MANUAL: DM1005 PAGE 7 OPERATING INSTRUCTIONS (continued) SETTING With the press locked in the downward position, turn the pressure knob PRESSURE clockwise to increase pressure or counterwise to reduce it. Use it to adjust the vertical position of the top platen in relation to the bottom platen during the lock-in.
- Page 9 INSTRUCTION MANUAL: DM1005 PAGE 8 OPERATING INSTRUCTIONS (continued) SETTING CONTROL PANELS (continued) Fig. 5 Fig. 6 Fig. 7 Fig. 8 4). The selected temperature is shown on the lower line of the display. 5. Press Set button again (Fig. 5) to go to the timer setting mode. 6. Press Up or Down buttons to select the desired time in seconds (Fig. 6). 7. Press Set button to go to the temperature scale selection mode (Fig. 7). Tip: Depending on your machine’s default settings, you may either see “F”...
- Page 10 INSTRUCTION MANUAL: DM1005 PAGE 9 OPERATING INSTRUCTIONS (continued) PRESSING 1. Wait until the platens heat up to the desired temperature (Fig. 11). Tip: Once heating is finished, the heating icons are turned off. 2. Place the prepared material in the center of the bottom platen 3. Lower the press handle locking in the press. 4. Press TIMER button on the control panel to start the countdown (Fig. 12). The countdown is now shown on the lower line of the display. 5. Wait until the countdown ends and the press starts beeping.
- Page 11 INSTRUCTION MANUAL: DM1005 PAGE 10 ROSIN PRESSING TIPS (continued) PLANT press mold. MATERIAL (continued) Place the puck inside a folded parchment paper sheet. Leave some space between the fold and the puck to avoid tearing the parchment paper during pressing.
-
Page 12: Technical Specifications
INSTRUCTION MANUAL: DM1005 PAGE 11 ROSIN PRESSING TIPS (continued) MORE Please see our website and subscribe to our newsletter and Dulytek social INFORMATION media pages for more tips, innovations, industry news, and discounts. TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DM1005 DM1005-E...
