- Page 1 HEAT PRESS MODEL No: DHP7 INSTRUCTION MANUAL CONTACT Seatle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DHP7 Press Features and Controls - Front DHP7 Press Features and Controls - Back PAGE 7 OPERATING INSTRUCTIONS Operating Warning Preparing Press Starting Press Setting Control Panel...
-
Page 3: Safety Precautions
PAGE 2 INTRODUCTION THANK YOU FOR SUPPORTING A US SMALL BUSINESS! DULYTEK DHP7 hydraulic heat press is a machine engineered and manufactured for personal use or use in research laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing industries. READ BEFORE... - Page 4 INSTRUCTION MANUAL: DHP7 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
• DO NOT exceed the rated capacity. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. - Page 6 ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine. If anything is missing, contact DULYTEK. 1. DULYTEK DHP7 Heat Press; 2. Jack Handle; 3. 4 x Suction Cup Feet with Cap Nuts;...
-
Page 7: Getting Familiar
INSTRUCTION MANUAL: DHP7 PAGE 6 UNPACKING (continued) RECOMMENDED 4. DripTek stand (sold separately mount compatible with the DHP7 press) PARTS (continued) Please see PRESSING TIPS (https://bit.ly/2YuM8pR) for more information. GETTING FAMILIAR DHP7 PRESS Press Handle FEATURES AND CONTROLS - FRONT Top Platen Bottom Platen Jack Handle Socket Control Panel Overload Valve Cap Nut Suction Cup Foot Release Valve... - Page 8 It protects the bottle jack and its parts from building up more pressure than it is designed to handle. For more information, please contact us at help@dulytek. PREPARING 1. Attach the four enclosed suction cup feet...
- Page 9 INSTRUCTION MANUAL: DHP7 PAGE 8 OPERATING INSTRUCTIONS (continued) PREPARING 2. Prepare materials you wish to press. Please see PRESSING TIPS (https:// bit.ly/2YuM8pR) for more information. PRESS 3. Make sure the press stands on a flat sturdy countertop. (continued) 4. Ensure the press is clean and free of residue or dust buildup. 5. Make sure all switches and controls are turned OFF.
- Page 10 INSTRUCTION MANUAL: DHP7 PAGE 9 OPERATING INSTRUCTIONS (continued) SETTING The selected temperature is shown on the lower line of the display. CONTROL 5. Press Set button again (Fig. 5) to go to the timer setting mode. PANEL 6. Press Up or Down buttons to select the desired time in seconds (continued) (Fig. 6).
- Page 11 INSTRUCTION MANUAL: DHP7 PAGE 10 OPERATING INSTRUCTIONS (continued) PRESSING 1. Wait until the platens heat up to the desired temperature (Fig. 11). Tip: Once heating is finished, the heating icons are turned off. 2. Place the prepared material in the center of the bottom platen 3. Pump up and down the jack handle . The bottom platen starts moving up. Continue pumping until the desired pressure between the platens is reached.
-
Page 12: Troubleshooting And Maintenance
Bleed air from bottle jack Air in bottle jack (see YouTube videos) BOTTLE JACK The DHP7 hydraulic bottle jack is removable and replaceable. Please see the REPLACEMENT following Dulytek YouTube video instructions on how to replace bottle jacks: 1. How to Remove Bottle Jack - https://youtu.be/kp6wSbJWMpc 2. How to Install Bottle Jack - https://youtu.be/j0nzHXQ-5lQ ©... -
Page 13: Technical Specifications
INSTRUCTION MANUAL: DHP7 PAGE 12 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DHP7 DHP7-E Press Force 14000 lb / 7 Ton Power 420 W Current 3.8 A 1.9 A Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates Platen Size 2.5 x 6 inch / 64 x 152 mm Temperature Range up to 302 °F / 150 °C Timer Range...
