- Page 1 HEAT PRESS MODEL No: DM800 INSTRUCTION MANUAL CONTACT Seatle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 HANDLING PRECAUTIONS PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DM800 Press Features and Controls PAGE 7 OPERATING INSTRUCTIONS Preparing Press Adjusting Pressure Starting Press Setting Control Panel Pressing Turning Off Press Cleaning Press Plates...
-
Page 3: Copyright Notice
INSTRUCTION MANUAL: DM800 PAGE 2 INTRODUCTION DULYTEK DM800 manual heat press is engineered and manufactured for personal use or use in research laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing indus- tries. Its best applications are for personal use. - Page 4 INSTRUCTION MANUAL: DM800 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
NOT attempt to use the equipment with a two-prong electrical cord or any other way without proper grounding. • Contact DULYTEK if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. -
Page 6: Item Checklist
DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine. If anything is missing, contact DULYTEK. 1. DULYTEK DM800 Heat Press; 2. AC Power Cord; 3. Instruction Manual. -
Page 7: Getting Familiar
INSTRUCTION MANUAL: DM800 PAGE 6 GETTING FAMILIAR DM800 PRESS FEATURES AND CONTROLS (front) Press Handle Pressure Knob Top Platen Bottom Platen © 2020 Dulytek Seattle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com All rights reserved... - Page 8 INSTRUCTION MANUAL: DM800 PAGE 7 GETTING FAMILIAR (continued) DM800 PRESS FEATURES AND CONTROLS (back) Control Panel ON/OFF Switch AC Power Cord Socket OPERATING INSTRUCTIONS PREPARING 1. Prepare materials you wish to press. Please see PRESSING TIPS (https:// PRESS bit.ly/2YuM8pR) for more information. 2. Make sure the press stands on a flat sturdy countertop. 3. Make sure all switches and controls are turned off. 4. Insert the AC power cord that came with the product into the press AC...
- Page 9 INSTRUCTION MANUAL: DM800 PAGE 8 OPERATING INSTRUCTIONS (continued) ADJUSTING Turn the pressure knob clockwise to increase pressure or counterwise to PRESSURE reduce it. Use it to adjust the vertical position of the top platen. A larger amount of starting material may require a larger distance between the platens to successfully close the press.
- Page 10 INSTRUCTION MANUAL: DM800 PAGE 9 OPERATING INSTRUCTIONS (continued) SETTING CONTROL PANEL (continued) Fig. 4 Fig. 5 Fig. 6 5. Press Set button again (Fig. 5) to go into the timer setting mode. 6. Press Up or Down buttons to select the desired time in seconds (Fig. 6). 7. Press Set button to go to the temperature scale selection mode (Fig. 7). Tip: Depending on your machine’s default settings, you may either see “F”...
- Page 11 INSTRUCTION MANUAL: DM800 PAGE 10 OPERATING INSTRUCTIONS (continued) PRESSING (continued) Fig. 10 Fig. 11 Fig. 12 3. Lower the press handle 4. Press TIMER button on the control panel to start the countdown (Fig. 12). The countdown is now shown on the lower line of the display. 5. Wait until the countdown ends and the press starts beeping.
-
Page 12: Technical Specifications
INSTRUCTION MANUAL: DM800 PAGE 11 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DM800 DM800-E Press Force 1350 lb / 0.6 Ton Power 120 W Current 1.1 A 0.6 A Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates Platen Size 2.5 x 3 inch / 64 x 76 mm Temperature Range up to 302 °F / 150 °C...
