- Page 1 HEAT PRESS MODEL No: DHP20 INSTRUCTION MANUAL CONTACT Seattle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DHP20 Press Features and Controls - Front DHP20 Press Features and Controls - Back PAGE 7 OPERATING INSTRUCTIONS Operating Warning Preparing Press Starting Press Setting Control Panel...
-
Page 3: Copyright Notice
INSTRUCTION MANUAL: DHP20 PAGE 2 INTRODUCTION DULYTEK DHP20 hydraulic heat press is a machine engineered and manufactured for personal use or use in research laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing industries. READ BEFORE To avoid accidents, first read SAFETY PRECAUTIONS (PAGE 2) and OPERATING HANDLING PRECAUTIONS (PAGE 4). MACHINERY Read this manual carefully to ensure you use the press correctly. - Page 4 INSTRUCTION MANUAL: DHP20 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
• DO NOT exceed the rated capacity. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. -
Page 6: Item Checklist
DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine. If anything is missing, contact DULYTEK. 1. DULYTEK DHP20 Heat Press; 5. AC Power Cord; 2. Jack Handle;... -
Page 7: Recommended Parts
INSTRUCTION MANUAL: DHP20 PAGE 6 UNPACKING (continued) RECOMMENDED 6. DHP20 compatible DripTek stand (sold separately) PARTS (continued) Please see PRESSING TIPS (https://bit.ly/2YuM8pR) for more information. GETTING FAMILIAR DHP20 PRESS Press Handle FEATURES AND CONTROLS - FRONT Top Platen Bottom Platen Control Panel Jack Handle Socket Jack Handle Release Valve Overload Valve © 2020 Dulytek Seattle, WA 98105 help@dulytek.com... - Page 8 The overload valve is pre-set at the factory and should not be touched during normal operation of the press. It protects the bottle jack and its parts from building up more pressure than it is designed to handle. For more information, please contact us at help@dulytek. PREPARING 1. Make sure the press stands on a flat sturdy countertop.
- Page 9 INSTRUCTION MANUAL: DHP20 PAGE 8 OPERATING INSTRUCTIONS (continued) PREPARING brackets to both sides of the press using four (4) bracket screws as PRESS shown in the picture above. Slide the brackets to the front and tighten the (continued) screws. 3. Prepare materials you wish to press. Please see PRESSING TIPS (https:// bit.ly/2YuM8pR) for more information. 4. Ensure the press is clean and free of residue or dust buildup.
- Page 10 INSTRUCTION MANUAL: DHP20 PAGE 9 OPERATING INSTRUCTIONS (continued) Tip: Enter the temperature either in °F or °C; you will be able to select the SETTING temperature scale later. CONTROL PANEL 3. Press Set button again (Fig. 3) to go to the temperature setting mode (continued) for the bottom platen. 4. Press Up or Down buttons to select the desired temperature (Fig. 4). The selected temperature is shown on the lower line of the display. Fig. 5 Fig. 6 Fig. 7 Fig. 8 5. Press Set button again (Fig. 5) to go to the timer setting mode. 6. Press Up or Down buttons to select the desired time in seconds (Fig. 6).
- Page 11 INSTRUCTION MANUAL: DHP20 PAGE 10 OPERATING INSTRUCTIONS (continued) SETTING 9. Press Set button once more (Fig. 9) to record all control panel’s CONTROL settings. The platens start heating, and the heating icons are now displayed PANEL on the screen (Fig. 10). (continued) PRESSING 1. Wait until the platens heat up to the desired temperature (Fig. 11). Tip: Once heating is finished, the heating icons are turned off. 2. Place the prepared material in the center of the bottom platen 3.
-
Page 12: Technical Specifications
INSTRUCTION MANUAL: DHP20 PAGE 11 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DHP20 DHP20-E Press Force 40000 lb / 20 Ton Power 825 W Current 7.5 A 3.75A Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates Platen Size 3 x 8 inch / 76 x 203 mm Temperature Range up to 302 °F / 150 °C...
