Page 1: Instruction Manual
HEAT PRESS MODEL No: DM1000 INSTRUCTION MANUAL CONTACT Dulytek Equipment help@dulytek.com © 2018 Dulytek All rights reserved Seatle, WA 98105 www.dulytek.com... - Page 2 INSTRUCTION MANUAL: DM1000 PAGE 1 TABLE OF CONTENTS PAGE 2 INTRODUCTION Read Before Operating Machinery Copyright Notice Disclaimer PAGE 3 SAFETY PRECAUTIONS PAGE 4 HANDLING PRECAUTIONS PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR...
- Page 3 INSTRUCTION MANUAL: DM1000 PAGE 2 INTRODUCTION DULYTEK DM1000 manual heat press is a machine engineered and manufactured for solvent-less plant rosin oil extraction for further use in research laboratories, pharmaceutical, cosmetic, food pro- cessing, and brewing industries. READ BEFORE To avoid accidents, first read SAFETY PRECAUTIONS (PAGE 3) and HAN- OPERATING DLING PRECAUTIONS (PAGE 4).
-
Page 4: Safety Precautions
Please make sure to thoroughly read, understand, and follow these precautions before using the product. If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. -
Page 5: Handling Precautions
NOT attempt to use the equipment with a two-prong electrical cord or any other way without proper grounding. • Contact DULYTEK if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. - Page 6 4. Remove any protective or promotional labels from the press and other parts if applicable. 5. Examine the heat press after unpacking for any damage. If found one, take a picture and contact DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine.
-
Page 7: Getting Familiar
INSTRUCTION MANUAL: DM1000 PAGE 6 GETTING FAMILIAR DM1000 PRESS FEATURES AND Pressure Knob CONTROLS Temperature Control Panel Timer Control Panel AC Power Cord Socket ON / OFF Switch Press Handle Top Platen Bottom Platen OPERATING INSTRUCTIONS PREPARING 1. Make sure the press stands on a flat sturdy countertop. THE PRESS 2. - Page 8 INSTRUCTION MANUAL: DM1000 PAGE 7 OPERATING INSTRUCTIONS (continued) SETTING Turn the pressure knob clockwise to increase pressure or counterwise to PRESSURE reduce it. Use it to adjust the vertical position of the top platen in relation to the bottom platen during the lock-in. The larger amount of pressing material may require a larger distance between the platens to successfully close the press.
- Page 9 INSTRUCTION MANUAL: DM1000 PAGE 8 OPERATING INSTRUCTIONS (continued) SETTING Set up the desired press time in seconds using the timer control panel TIMER 1. Press SET button on the timer control panel (Figure 5). SET TIME indicator becomes lit. 2. Press UP and DOWN buttons until the desired time in seconds is shown on the display (Figure 6).
-
Page 10: Technical Specifications
INSTRUCTION MANUAL: DM1000 PAGE 9 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DM1000 DM1000-E Press Force 900 lb Power 900 W Current Voltage 110 V 220 V Frequency 50 / 60 Hz Dual Heating Plates Platen Size 3 x 5 inch / 76 x 127 mm Temperature Range 0 - 750 °F...
