- Page 1 HEAT PRESS MODEL No: DW8000 INSTRUCTION MANUAL CONTACT Seatle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
- Page 2 HANDLING PRECAUTIONS PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Recommended Parts PAGE 6 GETTING FAMILIAR DW8000 Press Features and Controls PAGE 6 OPERATING INSTRUCTIONS Preparing and Starting Press Setting Control Panel Pressing Turning Off Press Cleaning Press Plates PAGE 10...
-
Page 3: Safety Precautions
INSTRUCTION MANUAL: DW8000 PAGE 2 INTRODUCTION DULYTEK DW8000 hybrid heat press is a machine engineered and manufactured for personal use or use in research laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing industries. READ BEFORE To avoid accidents, first read SAFETY PRECAUTIONS (PAGE 2) and OPERATING HANDLING PRECAUTIONS (PAGE 4). MACHINERY Read this manual carefully to ensure you use the press correctly. - Page 4 INSTRUCTION MANUAL: DW8000 PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.
-
Page 5: Handling Precautions
• DO NOT exceed the rated capacity. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using. - Page 6 DULYTEK at help@dulytek.com immediately. ITEM Before starting, please make sure that the following items are included with CHECKLIST your press machine. If anything is missing, contact DULYTEK. 1. DULYTEK DW8000 Heat Press; 2. AC Power Cord; 3. Instruction Manual.
-
Page 7: Getting Familiar
INSTRUCTION MANUAL: DW8000 PAGE 6 GETTING FAMILIAR DW8000 PRESS FEATURES AND Control Panel CONTROLS Up Button Down Button Power Button Top Platen Bottom Platen AC Power Cord Socket On/Off Switch OPERATING INSTRUCTIONS PREPARING AND 1. Prepare materials you wish to press. Please see PRESSING TIPS (https:// STARTING bit.ly/2YuM8pR) for more information. - Page 8 INSTRUCTION MANUAL: DW8000 PAGE 7 OPERATING INSTRUCTIONS (continued) socket and then plug its other end into an electrical outlet. PREPARING AND 4. Flip On/Off switch and press Power button to turn on the press. The STARTING control panel lights up. PRESS (continued) SETTING 1. Press SET button on the control panel (Fig. 1) to go to the temperature CONTROL setting mode for the top platen. PANEL 2. Press Up or Down buttons to select the desired temperature (Fig.
- Page 9 INSTRUCTION MANUAL: DW8000 PAGE 8 OPERATING INSTRUCTIONS (continued) SETTING CONTROL PANEL (continued) Fig. 7 Fig. 8 Fig. 9 7. Press SET button to go to the temperature scale selection mode (Fig. 7). Tip: Depending on your machine’s default settings, you may either see “F” or “C” on the display indicating the currently selected temperature scale (°F or °C). 8. Press Up or Down buttons to select either °F or °C (Fig. 8) OR skip this step if you are satisfied with the current selection. 9. Press SET button once more (Fig. 9) to record all control panel’s settings. The platens start heating, and the heating icons are now displayed on the screen (Fig. 10).
- Page 10 INSTRUCTION MANUAL: DW8000 PAGE 9 OPERATING INSTRUCTIONS (continued) increases the risk of bag blowouts. PRESSING 5. Press Timer button on the control panel to start the countdown (Fig. (continued) 12). The countdown is now shown on the lower line of the display. 6. Wait until the countdown ends and the press starts beeping. 7. Press Timer button again to turn off the timer and stop beeping. 8. Press and hold Up button to lift up the top platen 9.
-
Page 11: Technical Specifications
INSTRUCTION MANUAL: DW8000 PAGE 10 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DW8000 DW8000-E Press Force 8000 lb / 4 Ton Power 800 ~ 1800 W Current 7.3 ~ 16.3 A 3.7 ~ 8.2 A Voltage 110 V 220 V Frequency 50 Hz Dual Heating Plates...
