Dulytek DE40K Instruction Manual

Heat press
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HEAT PRESS
MODEL No: DE40K
INSTRUCTION MANUAL
CONTACT
Seattle, WA 98105
United States
help@dulytek.com
www.dulytek.com
© Dulytek
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE40K and is the answer not in the manual?

Questions and answers

Related Manuals for Dulytek DE40K

Summary of Contents for Dulytek DE40K

  • Page 1 HEAT PRESS MODEL No: DE40K INSTRUCTION MANUAL CONTACT Seattle, WA 98105 help@dulytek.com © Dulytek All rights reserved United States www.dulytek.com...
  • Page 2 PAGE 5 UNPACKING Unpacking Precautions Unpacking Instructions Item Checklist Required Equipment Recommended Parts PAGE 6 GETTING FAMILIAR DE40K Press Features and Controls PAGE 7 OPERATING INSTRUCTIONS Operating Warning Preparing & Starting Press Operation Modes Freestyle Mode: Setting Controls Pressing Automatic Mode:...

  • Page 3: Copyright Notice

    INSTRUCTION MANUAL: DE40K PAGE 2 INTRODUCTION DULYTEK DE40K hybrid heat press is an industrial strength machine engineered and manufactured for mostly commercial use in research laboratories, pharmaceutical, cosmetic, food processing, textile printing, and brewing industries. READ BEFORE To avoid accidents, first read SAFETY PRECAUTIONS (PAGE 2) and OPERATING HANDLING PRECAUTIONS (PAGE 4).
  • Page 4 INSTRUCTION MANUAL: DE40K PAGE 3 SAFETY PRECAUTIONS (continued) If product is damaged, appears to be damaged, or malfunctions, contact DULYTEK customer service at help@dulytek.com. WARNING: Follow the warnings below. Otherwise, death or serious injuries may occur. • Use this product only as described in this manual.

  • Page 5: Handling Precautions

    • DO NOT exceed the rated capacity. • Contact DULYTEK at help@dulytek.com if the equipment does not start or if smoke or unusual odors are detected. • Always turn the machine OFF and unplug it when done using.

  • Page 6: Item Checklist

    1. DULYTEK DE40K Heat Press; 2. AC Power Cord; 3. Instruction Manual. REQUIRED The DE40K must be used together with a standard 100 - 150 PSI pneumatic EQUIPMENT (air) compressor. RECOMMENDED The following items are recommended for use with this machine: PARTS 1.

  • Page 7: Recommended Parts

    INSTRUCTION MANUAL: DE40K PAGE 6 UNPACKING (continued) RECOMMENDED 3. Humidity packs; PARTS 4. Collection tools, glass stamp, etc. (continued) Please see PRESSING TIPS (https://bit.ly/2YuM8pR) for more information. GETTING FAMILIAR DE40K PRESS Upper Plate FEATURES AND CONTROLS Lower Plate Emergeny Stop Button .

  • Page 8: Operating Warning

    Tip: If the pressure drops below 70 PSI during the press operation, turn the air compressor on again until it reaches at least 100 PSI. 7. Turn on the DE40K by pressing Power On/Off button . The touchscreen control lights up.
  • Page 9 INSTRUCTION MANUAL: DE40K PAGE 8 OPERATING INSTRUCTIONS (continued) FREESTYLE 1. Tap Menu on the touchscreen control (Fig. F-1) and select MODE: Freestyle from the dropdown. Freestyle Mode - Settings screen appears (Fig. F-2). SETTING CONTROLS Fig. F-1 Fig. F-2 Fig. F-3 2.
  • Page 10 INSTRUCTION MANUAL: DE40K PAGE 9 OPERATING INSTRUCTIONS (continued) FREESTYLE temperature) field. MODE: 3. Tap the center of U Temp (upper plate temperature) field (Fig. F-7) and SETTING use the keypad to select your desired temperature for the upper plate. Tap CONTROLS Enter (Fig.

  • Page 11: Freestyle Mode

    INSTRUCTION MANUAL: DE40K PAGE 10 OPERATING INSTRUCTIONS (continued) FREESTYLE 2. When heating is done, position your material in the center of the lower . Tip: Heating is done when the actual temperatures reach the set MODE: plate PRESSING parameters and the heating indicators are turned off (Fig. F-16).
  • Page 12 INSTRUCTION MANUAL: DE40K PAGE 11 OPERATING INSTRUCTIONS (continued) FREESTYLE MODE: PRESSING (continued) Fig. F-19 Fig. F-20 Fig. F-21 to leave Freestyle mode if done pressing. A popup appears asking to confirm your selection (Fig. F-20). Tap Yes. The initial home page is now shown on the screen (Fig.
  • Page 13 INSTRUCTION MANUAL: DE40K PAGE 12 OPERATING INSTRUCTIONS (continued) AUTOMATIC MODE: SETTING CONTROLS (continued) Fig. A-4 Fig. A-5 Fig. A-6 3. Tap the center of U Temp field (Fig. A-7) and use the keypad to select your desired upper plate temperature. Tap Enter (Fig. A-8) to save the number and close the keypad.
  • Page 14 INSTRUCTION MANUAL: DE40K PAGE 13 OPERATING INSTRUCTIONS (continued) AUTOMATIC 5. Tap the center of Force field (Fig. A-13) and enter the desired press force MODE: in pounds using the keypad. Tap Enter (Fig. A-14) to save the number and SETTING close the keypad.
  • Page 15 INSTRUCTION MANUAL: DE40K PAGE 14 OPERATING INSTRUCTIONS (continued) AUTOMATIC right lower corner of the corresponding fields, and their live readings are MODE: displayed in the center. PRESSING 2. When heating is done, position your material in the center of the lower...

  • Page 16: Troubleshooting

    INSTRUCTION MANUAL: DE40K PAGE 15 OPERATING INSTRUCTIONS (continued) AUTOMATIC popup appears asking to confirm your selection (Fig. A-26). Tap Yes. The MODE: initial home page is shown on the screen (Fig. A-27). PRESSING 10. Press Power On/Off button to turn off the machine. Unplug the press (continued) and compressor AC power cords from the electrical outlets.

  • Page 17: Technical Specifications

    INSTRUCTION MANUAL: DE40K PAGE 16 TECHNICAL SPECIFICATIONS PARAMETER USA MARKET EU MARKET Model DE40K DE40K-E Press Force 44000 lb / 20 Ton Power 2000 W Current 18.18 A 9.09A Voltage 110 V 220 V Frequency 50 Hz Dual Heating Plates...

This manual is also suitable for:

De40k-e
