3.2.5 Frequ, calibration and joystick mode selection of intelligent
remote control
1. Frequency
If you buy the intelligent remote control and aircraft packaged in the form of

a package, you have set the intelligent remote control and the aircraft in
advance when you leave the factory, no need to set again, and the equipment
can be directly used after activation.
For frequency operation using Autel E nterprise A pp, refer to the following

specific steps for frequency operation:
1. Short press on the aircraft fuselage?? After the (position) opposite frequency
button enters the opposite frequency state of the aircraft, the flight indicator light
of the aircraft will be in the high-frequency flashing state (to be confirmed);
2. Open the remote control and run Autel E nterprise A pp, enter the "intelligent
Photography" interface, click the gear icon in the upper right corner, enter the
Settings menu, click "Remote Control-> Remote Control to frequency> Main
Remote Control to frequency", wait for a few seconds until the frequency
matching is successful.
point out
If the intelligent remote control and the aircraft are on frequency, please

keep the distance between them within 50 cm
2. calibration
If the smart remote control is used abnormally, it is recommended to calibrate the
smart remote control. You can use the Autel E nterpriseApp to calibrate the rocker
and keys, following the following steps:
Open the remote control. Enter the App Camera Interface> Set (

Remote> Remote Calibration. There will be two meter word shapes and two
horizontal bars, representing the left and right joystick and the left and right
dial wheel.
Shaker calibration: Push and hold the joystick in eight directions until a

beep is heard each time.
Wheel calibration: Turn the dial wheel clockwise until a beep is heard, and

then turn counterclockwise until a beep is heard.
43
)>
