ITV0000・0090/ Specific Product Precautions
Be sure to read this before handling the products.
Refer to the "Handling Precautions for SMC Products" and the "Operation
Manual" on the SMC website: https://www.smcworld.com
Warning
1. Use compressed air as the fluid used.
2. Do not use compressed air that contains chemicals,synthetic oils that include organic
solvents, salt, corrosivegases, etc., as doing so may result in a malfunction.
Caution
1. Install an air filter near this product on the supply side. Select an air filter with a filtration
size of 5 μm or smaller.
2. Compressed air that contains a large amount of drainage can result in the malfunction of this
product and other pneumatic equipment. Therefore, take appropriate measures to ensure air
quality, such as by providing an aftercooler, air dryer, or water separator.
3. If excessive carbon dust is generated by the compressor, it may adhere to the inside of this
product and cause it to malfunction.
Refer to the "SMC Air Preparation System" for further details on compressed air quality.
Caution
Connect the cable to the connector on the body with the wiring arranged as shown
below. Proceed carefully, as incorrect wiring can result in damage.
Further, use DC power with sufficient capacity and a low ripple.
Air Supply
Wiring
*1 A right angle type cable is also available.
The entry direction for the right angle type
connector is downward (SUP port side).
Never turn the connector as it is not
designed to turn. Using force to turn the
connector will damage the connector
coupling.
