- Page 1 SR119 - TRIPLE SPRING RIDER Installation Instructions METAL PLATE SR119 - TRIPLE SPRING RIDER PLAYTEC TOP TIMBER LENGHTS TIMBER CONNECTORS SPRING ASSEMBLY REF: SR119 pg 1 of 9 18.10.2023...
-
Page 2: Additional Parts
ADDITIONAL PARTS SEASAW SEAT SEASAW HANDLE M12 COVERED END CAP M8X120 WOOD SCREWS M8X80 WOOD SCREWS M12 X160 M8 COVERED END CAP N12 (NYLOC) REF: SR119 pg 2 of 9 18.10.2023... -
Page 3: Foundation Details
FOUNDATION DETAILS CONCRETE REF: SR119 pg 3 of 9 18.10.2023... -
Page 4: Surfacing Details
SURFACING DETAILS 5045 Ø5029 REF: SR119 pg 4 of 9 18.10.2023... -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS ASSEMBLE THE METAL PLATE TO THE SPRING ASSEMBLIES ATTACH TIMBER LENGHTS TO THE METAL PLATE USING DRILLED HOLES REF: SR119 pg 5 of 9 18.10.2023... - Page 6 Using M12X160 CUP SQAURE BOLTS X9 / M12 COVERED END CAP X9 / M12 NYLOC X9 SCREW ON TIMBER CONNECTORS TO TIMBER LENGHTS Using M8X120 WOOD SCREWS X6 / TIMBER CONNECTORS X3 NOTE: SCREW USING HOLE DIMENSION BELOW SO SCREWS DONT CLASH REF: SR119 pg 6 of 9 18.10.2023...
- Page 7 Using M8X80 WOOD SCREWS X15 / SEASAW SEAT X3 / SEASAW HANDLES X3 / M8 COVERED ENDS X6 NOTE: ENSURE SEAT IS PLACED IN LINE END OF TIMBER AND HANDLE IS DIRECTLY IN FRONT OF IT AS SHOWN REF: SR119 pg 7 of 9 18.10.2023...
- Page 8 INSTALLATION INSTRUCTIONS ONCE FULLY ASSEMBLED INSTALL POSTS INTO GROUND REF: SR119 pg 8 of 9 18.10.2023...
-
Page 9: Additional Dimensions
ADDITIONAL DIMENSIONS 1820 SEAT HEIGHT - 0.54M REF: SR119 pg 9 of 9 18.10.2023...
