- Page 1 G S 3 4 8 A S S E M B L Y I N S T R U C T I O N S...
- Page 2 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. Do Not wrench tighten until the end of step 5. Attach Left Main Base Frame (A) to Left Rear Upright Frame (C) using: Two A2 (1/2”...
- Page 3 S T E P...
- Page 4 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. Do Not wrench tighten until the end of step 5. Attach Right Main Base Frame (B) to Right Rear Upright Frame (C) using: Two A2 (1/2”...
- Page 5 S T E P...
- Page 6 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. Do Not wrench tighten until the end of step 5. Connect Left Main Base Frame (A) to Right Main Base Frame (B) with the Foot Plate (T) using: Two A6 (3/8”...
- Page 7 S T E P...
- Page 8 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. Do Not wrench tighten until the end of step 5. Attach Middle Frame (G) and two Weight Horns (F) to each Rear Upright Frame (C) using: Four A4 (1/2”...
- Page 9 S T E P...
- Page 10 S T E P Be careful to assemble all components in the sequence they are presented. Insert two Shaft Collar (D3) to the top of each Rear Upright Frame (C) and turn to hold in place. Insert Guide Rod (P) into and through Shaft Collar (D3) on each side. Slide each Smith Bar End (L), which is pre-asembled with Smith Bar (M), onto the Guide Rods (P).
- Page 11 S T E P...
- Page 12 G S 3 4 8 M a i n f r a m e P a r t s L i s t KEY# QTY PART# DESCRIPTION GS348LMBF-A LEFT MAIN BASE FRAME GS348RMBF-B RIGHT MAIN BASE FRAME GS348URF-C UPRIGHT REAR FRAME GS348LUFF-D LEFT UPRIGHT FRONT FRAME GS348RUFF-E...
- Page 13 G S 3 4 8 H a r d w a r e L i s t KEY# QTY PART# DESCRIPTION AHB.5X1.25PT ALLEN HEAD BOLT 1/2” X 1 1/4” PARTIAL THREAD HEX.5X2.75PT HEX HEAD BOLT 1/2” X 2 3/4” PARTIAL THREAD HEX.5X3PT HEX HEAD BOLT 1/2”...
