Summary of Contents for ViewZ VZ-156PM-4K

  • Page 1 User Guide...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS The device has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment, the device should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 3 (Native/Rec.709/User1~User3).  Support to upload 3D LUT table via USB port.  Equip HDR function.  Image flip offers great convenience for user’s user to place the monitor with various mounting methods under different conditions. Users can view the monitor normally no matter what mounting angles. ...

  • Page 4: Table Of Contents

    Contents 1. PRODUCT DESCRIPTION ................3 2. SUN SHADE INSTALLATION ..............7 3. MENU SETTING ..................8 4. ACCESSORIES ..................23 5. PARAMETERS ..................25 6. TROUBLE SHOOTING ................26...

  • Page 5: Product Description

    1. PRODUCT DESCRIPTION Front 1. Speaker 2. SDI Signal switch to SDI mode when light on. 3. HDMI 1 ~ 4 Signal switch to HDMI mode when light on. 4. DVI Signal switch to DVI mode when light on. 5. VGA Signal switch to VGA mode when light on.
  • Page 6 Press to enter menu. Press to enter option in the menu. 7. ◄ Select option in the menu. Decrease the option value. Before enter the menu, single press to activate volume, press again to decrease the volume. 8. ► Select option in the menu. Increase the option value.
  • Page 7 Back 1. Handle (Only available for BM230/BM280) 2. VESA 75×75 & VESA 100×100 mounting port 3. USB port 4. TALLY port 5. VGA input port 6. DVI input port 7. HDMI input port×4。 HDMI 1 & HDMI 2 : HDMI2.0, support 4K 60Hz HDMI 3 &...

  • Page 8: Sun Shade Installation

    ① ②③ ……... ④ +15V 11. Power switch "II" is battery power, "o" is power off, "I" is DC power. 2. SUN SHADE INSTALLATION 1. Put the sun shade on the suitcase, and match the magnets on both sides. 2. As shown below after finished.

  • Page 9: Menu Setting

    3. MENU SETTING Please check whether the device is connected well or not. 3-1. F1~F4 user definable shortcut buttons Long keep pressing any one of the 4 buttons for 3-5 seconds to activate shortcut menu setting. Option selected will be highlighted as white. option will be highlighted as yellow, unavailable option will be highlighted as gray.
  • Page 10 Time Code (Only available under SDI mode) Display Mode Disp Mirror Color Space Default options: F1：Color Space F2：Display Mode F3：Safety Marker F4：Aspect 3-2. ◄ / ► Buttons Operation Under non menu screen, press "◄/►" buttons to activate volume bar, Use "◄ / ►" buttons to select the desired option. Press the "MENU"...
  • Page 11 Brightness 0~100 Contrast 0~100 Saturation 0~100 0~100 Sharpness Color Space Native/Rec.709/User1~User3 Picture Off/Auto/HDR10 Backlight Mode Standard/Outdoor/User Backlight 0~100 Temperature 9300/7500/6500/5800/User Red Gain 0~256 Note: Available only under Green Gain 0~256 “User” mode. Blue Gain 0~256 Brightness Adjust the general brightness of the LCD. For example, if it uses outside in bright conditions, increase the LCD brightness to make it easier to view.
  • Page 12 Adjust the color intensity. Press "◄/►" buttons to increase or decrease the color intensity. It means tint. Use this setting to choose the tint from 0 to 100. Sharpness Increase or decrease the sharpness of the image. When the sharpness of image is insufficient, the value of sharpness can be increased to make the image clearer.
  • Page 13  HDR is only available under HDMI 1 signal input.  HDR under AUTO or DHR10 mode, and the input signal support HDR, the below function is disabled: Contrast, Brightness, Saturation, Hue, Sharpness, Color Space, BackLight Color Temperature  [Auto] Automatically recognize whether the input HDMI signal supports HDR.
  • Page 14 3-3-2.Function Center Marker Select On, it will appear "+" marker on center of screen. Center Marker ON, OFF Safety Marker OFF, 95%, 93%, 90%, 88%, 85%, 80% Aspect Marker OFF, Full, 17:9, 16:9, 4:3, 1.85:1, 2.35:1 Aspect Full ,17:9, 16:9, 4:3, 1.85:1, 2.35:1 Underscan ON, OFF Pixel To Pixel...
  • Page 15 Safety Marker Use this setting to set off the safety marker or choose the one of the safety markers: [OFF], [95%], [93%], [90%], [88%], [85%], [80%]. Aspect Marker Display the different aspect of the displayed image. [OFF], [Full], [17:9], [16:9], [4:3], [1.85:1], [2.35:1].
  • Page 16 False Color This monitor has a false color filter to aid in the setting of camera exposure. As the camera Iris is adjusted, elements of the image will change color based on the luminance or brightness values. This enables proper exposure to be achieved without the use of costly, complicated external equipment.
  • Page 17 Histogram The histogram makes users view visually the exposure of whole and each RGM channels. It has the full contrast rang of video for easy color correction during post production. NOTE: Only available when under SDI mode. Time Code The Time Code supports Longitudinal time code (LTC) and Vertical interval time code (VITC).
  • Page 18 3-3-3. Display Mode Display Mode 1P，2P LR，2P TB，2P PIP，4P Display Mode The monitor presets 1P, 2P LR, 2P TB, 2P PIP, 4P five display modes. This function can be work with Select Region function to meet user’s requirement. For example: In 1P mode, images are scaled to fill the entire screen.
  • Page 19 Display Rotate and Display Mirror This setting support to flip the image to 0°, 90°, 180°, 270° modes. It is only available when single display. Display mirror This setting displays two different input signals to Light/Right or Up and Down, the user can choose it to view the images according to the requirement.
  • Page 20 3-3-6. Input Volume 0~100 NOTE: Only available Level Meter OFF/ON Audio when under SDI mode Audio Analog/Digital region 1~4 Source 3-3-7. Audio Input Signal switch to region selected according to users’ needs.
  • Page 21 Digital region 2~4 is only available under multi-displays mode and must activate the corresponding Region under Select Region function at the same time. 3-3-8. VGA Auto Adjust H Position 0~100 V Position 0~100 Clock Phase 0~100 3-3-9. System...
  • Page 22 Reset If there is any problem unknown, press to confirm after selecting. The monitor will return to default set. Menu Time Adjust the OSD displaying time form 10 to 60s. OSD H Position and OSD V Position Move OSD horizontally or vertically. Language Reset Press to confirm after selected.
  • Page 23 This setting is available when display in 2P LR, 2P TB, 2P PIP, 4P mode. The lines separate the different input signals means Border. 3-3-10. Information Information To display current information.

  • Page 24: Accessories

    4. ACCESSORIES 1. Folding sun shade cover 1 piece 2. TALLY connector (in bulk) 1 piece 3. V-mount or Anton Bauer mounts Power cable 1 piece 4. V-mount or Anton Bauer mount 1piece 5. Manual 1 copy 6. Carry-on suitcase 1 piece 7.

  • Page 26: Parameters

    5. PARAMETERS Display Screen 15.6” 8bit IPS 23.8” IPS 28” IPS Physical 3840×2160 3840×2160 3840×2160 Resolution Aspect Ratio 16：9 16：9 16：9 Brightness 330cd/㎡ 300cd/㎡ 300cd/㎡ Contrast 1000: 1 1000: 1 1000: 1 Viewing Angle 176°/ 176°(H/V) 178°/ 178°(H/V) 170°/ 160°(H/V) DC12~24V DC 12~24V DC12~24V...

  • Page 27: Trouble Shooting

    6. TROUBLE SHOOTING 1. Only black-and-white display. Check whether the color saturation is properly setup or not. 2. Power on but no pictures. Check whether the cables of HDMI, VGA，DVI and 3G-SDI are correctly connected or not. Please use the standard power adapter coming with the product package.
  • Page 28 Appendix 1 3D LUT of Loading Manual BM-4KS supports 3DLUT to load the color calibration document and the User Log by using flash disk Format Requirement： LUT format:  Type： .cube 3D Size： 17x17x17 Data Order： Table Order： USB flash disk version ...
  • Page 29 2-2. Enter the Lut Converter interface after input the Enter Key 2-3. Click Input File, then select *LUT 2-4. Click Output File, and then select the file name as required format. Such as: Rec709.cube, 3D Size： 17 Data Order：RGB, Table Order：RGB.
  • Page 30 Please note：The format which shown in Red Box above should be selected to RGB. 2-5. Click Generate Lut button to finish the transform. 3. USB Loading The USB flash disk must be formatted before using to make sure that there ...
  • Page 31 The device will be restarted automatically after completed. The whole updating process takes about 6 seconds according to the updated LUT name. Please activate and set up the updated LUT table under the menu after restart.  doesn’t need to be reset if the current updated LUT has been selected before updating.
