Chapter 3 Overview: Cisco ASR 1000 Series Aggregation Services Routers SPAs
•
•
•
Double-wide SPAs are not supported on Cisco ASR1000-SIP40.
Warning
The chassis models of the Cisco ASR 1000 Series Aggregation Services routers support a different
maximum number of Cisco ASR1000-SIP40 as follows:
•
•
Warning The Cisco ASR1000-SIP40 is not supported on Cisco ASR1002 (2 RU), Cisco ASR 1002-Fixed Router (2
RU-F), and Cisco ASR 1004 Router. The Cisco ASR1000-SIP40 at slots 4 and 5 of the Cisco ASR 1000
Series Router works like a Cisco ASR1000-SIP10.

1-Port and 3-Port Clear Channel OC-3 ATM SPA Overview

The 1-Port and 3-Port Clear Channel OC-3 ATM SPA is a single-height SPA that installs into one SIP
subslot. The 1-Port and 3-Port Clear Channel OC-3 ATM SPA with small form-factor pluggable (SFP)
optical transceiver modules provides SONET and SDH network connectivity with a per-port bandwidth
of 155.52 Mbps.
The following sections describe the 1-Port and 3-Port Clear Channel OC-3 ATM SPA:
•
•
•

1-Port and 3-Port Clear Channel OC-3 ATM SPA LEDs

The 1-Port and 3-Port Clear Channel OC-3 ATM SPA has three types of LEDs: two LEDs for each port
on the SPA and one STATUS LED, as shown in
OL-14126-12
Four half-height (¼ rate or full rate or combination) SPAs with upto 24 ports per SPA
Two full-height (¼ rate or full rate or combination) SPAs with upto 48 ports per SPA
Combination of two half-height and one full-height SPAs that do not exceed 96 ports
Cisco ASR 1006 Router — three SIPs
Cisco ASR 1013 Router — six SIPs
1-Port and 3-Port Clear Channel OC-3 ATM SPA LEDs, page 3-7
1-Port and 3-Port Clear Channel OC-3 ATM SPA Interface Specifications, page 3-8
1-Port and 3-Port Clear Channel OC-3 ATM SPA Cables and Connectors, page 3-8
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Hardware Installation Guide
1-Port and 3-Port Clear Channel OC-3 ATM SPA Overview
Figure 3-1.
3-7
