Chapter 5 Maintaining the Cisco 7206
Figure 5-4
Step 7 Move the port adapter lever to the locked position. (See
Note
This completes the procedure for installing a port or service adapter in the Cisco 7206 router.

Installing and Removing a Flash Memory Card

The I/O controller has two PC Card slots for Flash memory cards: slot 0 (lower) and slot 1 (upper).

Inserting a Flash Memory Card

Complete the following steps to insert a Flash memory card in either PC Card slot:
To avoid potential problems when inserting spare Flash memory cards in your Cisco 7206, we
Note
recommend that you reformat all of your Flash memory cards on a Cisco 7206 running one of the
recommended Cisco IOS software releases. The
page 5-12
OL-5102-02
Placing the Port Adapter Lever in the Locked Position
Note: This adapter installation
applies to any port or service
adapter.
If the lever does not move to the locked position, the adapter is not completely seated in the
midplane. Carefully pull the adapter half way out of the slot, reinsert it, and move the port
adapter lever to the locked position.
contains instructions that explain how to reformat a Flash memory card.

Installing and Removing a Flash Memory Card

FAST ETHERNET INPUT/OUTPUT CONTROLLER
Port adapter
handle
Port adapter
lever (locked
position)
Figure 5-4.)
"Reformatting a Flash Memory Card" section on
Cisco 7206 Installation and Configuration Guide
5-7
