Ethernet And Fast Ethernet Rj-45 Connection Equipment - Cisco 7206 - VXR Router Installation Manual

Connecting I/O Controller Cables
Table 3-3
Pin
14–17
12
11
13
3
4–7
9
10
8
18
19
2
22–39
1, 20, 21,
40
1. Any pins not indicated are not used.
2. Tx_CLK and Rx_CLK are provided by the external transceiver.

Ethernet and Fast Ethernet RJ-45 Connection Equipment

The RJ-45 port on the I/O controller is configurable for 100 Mbps full-duplex or half-duplex
(half-duplex is the default) and supports IEEE 802.3 (Ethernet) and IEEE 802.3u interfaces complaint
with 10BASET and 100BASETX specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 unshielded twisted-pair
(UTP) cables (refer to
are available commercially.
Figure 3-17
port.
Figure 3-17 RJ-45 Port and Plug
8 7 6 5 4 3 2 1
RJ-45 connector
Cisco 7206 Installation and Configuration Guide
3-18
MII Port Pinout
1
In Out I/O
– Yes –
Yes – –
– Yes –
– Yes –
– Yes –
Yes – –
Yes – –
Yes – –
Yes – –
Yes – –
Yes – –
– – Yes
– – –
– – –
Figure 3-15). Cisco Systems does not supply Category 5 UTP cables; these cables
shows the RJ-45 port and connector.
Description
Transmit Data (TxD)
Transmit Clock (Tx_CLK)
Transmit Error (Tx_ER)
Transmit Enable (Tx_EN)
MII Data Clock (MDC)
Receive Data (RxD)
2
Receive Clock (Rx_CLK)
Receive Error (Rx_ER)
Receive Data Valid (Rx_DV)
Collision (COL)
Carrier Sense (CRS)
MII Data Input/Output (MDIO)
Common (ground)
+5.0 volts (V)
Table 3-4 lists the pinouts and signals for the RJ-45
Chapter 3 Installing the Cisco 7206
2
OL-5102-02
