Installing and Removing a Flash Memory Card
Figure 5-5
c
Orient the Flash memory card so that its connector end faces the appropriate slot. (Refer to
Step 1
step a.)
Carefully guide the card into the slot until the card seats in the slot's connector and the eject button for
Step 2
the slot pops out toward you. (Refer to
Note
Cisco 7206 Installation and Configuration Guide
5-8
Inserting and Removing a Flash Memory Card
a
b
Flash memory cards do not insert all the way into the PC Card slots; the end of the card protrudes
from the I/O controller faceplate. Do not attempt to force the card past this point.
Figure 5-5, step b.)
