Rack-Mounting the Cisco 7206
Figure 3-8
Rack-mount
bracket
Figure 3-9
Rack-mount
bracket
Thread two M4 x 8-mm Phillips flathead screws through the rack-mount bracket and into the side of the
Step 3
chassis. Use a number 2 Phillips screwdriver to tighten the screws.
Repeat
Step 4
If you plan to include the cable-management brackets in your rear rack-mount configuration, align the
Step 5
first cable-management bracket to the threaded holes in the front side of the chassis. (Refer to
and
Figure
Step 6
Thread two M4 x 8-mm Phillips flathead screws through the bracket and into the chassis. Use a number
2 Phillips screwdriver to tighten the screws.
Repeat Step 5 and Step 6 for the other cable-management brackets.
Step 7
Cisco 7206 Installation and Configuration Guide
3-8
Installing the Rack-Mount Brackets on the Rear of the Chassis so the Front
Protrudes from the Rack
Cisco 7200
Series
Installing the Rack-Mount Brackets on the Rear of the Chassis so the Front
Is Recessed in the Rack
Cisco 7200
Series
Step 1
through
Step 3
for the other rack-mount bracket.
3-9.)
Cable-management bracket
Cable-management bracket
Chapter 3
Installing the Cisco 7206
ETHERNET-10BFL
FAST ETHERNET INPUT/OUTPUT CONTROLLER
ETHERNET-10BFL
FAST ETHERNET INPUT/OUTPUT CONTROLLER
Figure 3-8
OL-5102-02
