Starting the Cisco 7206

This completes the procedure for connecting DC-input power. Proceed to the
section on page 3-24

Starting the Cisco 7206

After installing your Cisco 7206 and connecting cables, start the router as follows:
Check for the following:
Step 1
•
•
•
•
•
•
Step 2 At the rear of the router, place the power switch on the power supply in the on (|) position. Repeat this
if a second power supply is installed. The green OK LED on the power supply turns on.
Step 3 Listen for the fans; you should immediately hear them operating.
Step 4 During the boot process, observe the system LEDs. The LEDs on most of the port adapters go on and off
in irregular sequence. Some may go on, go out, and go on again for a short time. On the I/O controller,
the IO power OK LED comes on immediately.
Step 5 Observe the initialization process. When the system boot is complete (a few seconds), the network
processing engine begins to initialize the port adapters and the I/O controller. During this initialization,
the LEDs on each port adapter behave differently (most flash on and off).
The enabled LED on each port adapter goes on when initialization is completed, and the console screen
displays a script and system banner similar to the following:
Cisco Internetwork Operating System Software
IOS (tm) 7200 Software (C7200-J-M), Version 11.1(17)CA
Copyright (c) 1986-1996 by cisco Systems, Inc.
Compiled Sun 21-Apr-96 04:10 by
When you start up the Cisco 7206 for the first time, the system automatically enters the setup command
Step 6
facility, which determines which port adapters are installed and prompts you for configuration
information for each one. On the console terminal, after the system displays the system banner and
hardware configuration, you will see the following System Configuration Dialog prompt:
At any point you may enter a questions mark '?' for help.
Use ctrl-c to abort configuration dialof at any prompt.
Default settings are in square brackets '[]'.
continue with configuration dialog? [yes]:
You have the option of proceeding with the setup command facility to configure the interfaces, or exiting
from setup and using configuration commands to configure global (system-wide) and interface-specific
parameters. You do not have to configure the interfaces immediately; however, you cannot enable the
interfaces or connect them to any networks until you have configured them.
Cisco 7206 Installation and Configuration Guide
3-24
to start the router.
Each port adapter is inserted in its slot and its respective port adapter lever is in the locked position.
The network processing engine and the I/O controller are inserted in their slots and their captive
installation screws are tightened.
All network interface cables are connected to the port adapters.
A Flash memory card is installed in its PC card slot.
Each power cable is connected and secured with the cable-retention clip.
The console terminal is turned on.
--- System Configuration Dialog ---
Chapter 3 Installing the Cisco 7206
"Starting the Cisco 7206"
