Installing the Cisco 7206
This chapter explains the procedures for installing and starting the Cisco 7206. The chapter contains the
following sections:
• Rack-Mounting the Cisco 7206, page 3-2
General Tabletop or Workbench Installation, page 3-9
•
• Providing a Chassis Ground Connection for the Router Chassis, page 3-12
Connecting Port Adapter Cables, page 3-14
•
• Connecting I/O Controller Cables, page 3-14
Connecting Power, page 3-20
•
Starting the Cisco 7206, page 3-24
•
For installation and startup procedures for a Cisco 7206 as a router shelf in a Cisco AS5800 Universal
Note
Access Server, refer to the Cisco AS5800 Universal Access Server documentation listed in the Preface,
"Related Documentation" section on page
Warning Before you install, operate, or service the system, read the Site Preparation and Safety Guide. This
guide contains important safety information you should know before working with the system.
To be installed and maintained by service personnel as defined by AS/NZS 3260. Incorrect connection
Warning
of this or connected equipment to a General Purpose Outlet could result in a hazardous situation. The
telecommunications lines must be disconnected before unplugging the main power connection and
while the housing is open.
A rack-mount and cable-management kit is included in the shipping container. The rack-mount brackets
in the kit are for mounting the Cisco 7206 in standard, 19-inch-wide, four-post equipment racks or
telco-type equipment racks. The rack-mount brackets are not suitable for use with other racks, such as
23-inch telco racks. The cable-management brackets are designed to relieve the strain on port adapter
interface cables that are installed on port adapters in a Cisco 7206. If you are installing an equipment
shelf or using mounting hardware other than that supplied with the chassis, review the guidelines in the
"Equipment Racks" section on page 2-4
section
If you do not plan to install your Cisco 7206 in an equipment rack, proceed to the
Workbench Installation" section on page
OL-5102-02
"General Tabletop or Workbench
C H A P T E R
xiv.
in Chapter 2, "Preparing for Installation,"
Installation" in this chapter.
3-9.
Cisco 7206 Installation and Configuration Guide
3
then proceed to the
"General Tabletop or
3-1
