TECHNICAL INFORMATION
Technical Information
Profile Code Charger Profile
P06 AGM
P07 OPP (*)
P04 AIRMIX
P09 WL20
P25 LOWCHG
P31 NXBLOC (*)
P29 NXSTND (*)
P30 NXFAST (*)
P32 NXP2V (*)
P33 NXPBLC (*)
ATP2V
NXSION (*)
6 6
(cont.)
Description
IUI profile. Max 0.20 C5. Auto battery capacity with Ph1 loops. Finish
time limitation. Can manually set battery capacity if required. Weekly
equalization is needed.
Opportunity charge PzQ cells. IU (main) & IUI pulse (daily) profile @0.25
C5. Finish current 5%. Must set daily full charge. If programmed
Wi-iQ battery monitoring device fitted, gives capacity, temp and voltage;
®
however, for safety if no communication, should manually set battery
capacity, temp and voltage. Weekly equalization is needed.
Pneumatic/Airmix profile. Must have air kit fitted to use this profile. IUI
profile Max 0.13 to 0.25 C5. Auto battery capacity with Ph1 loops. Can
manually set battery capacity if required. Weekly equalization is needed.
Water Less 20 battery, IUI profile (old WF200). Requires airmix and Wi-iQ
®
battery monitoring device comm. Weekly equalization is needed.
Low rate charge profile. IUI profile 0.09 to 0.13 C5. Manually set battery
capacity if required. Weekly equalization is needed.
For NexSys TPPL Bloc battery under normal charge. Charge rate 0.18 to
®
0.70 C5. Must set Battery Capacity, Temperature & Equalize values, or fit
properly programmed Wi-iQ
battery). If not installed or no comm, charger will use manual setup Ah and
temp. Weekly equalization is needed.
For NexSys ® TPPL 2V battery under normal charge. Charge rate 0.18 to 0.25
C5. Must set battery capacity, temperature & equalize values or fit properly
programmed Wi-iQ battery monitoring device (NexSys
®
installed or no comm, charger will use manual setup Ah and temp. Weekly
equalization is needed.
For NexSys TPPL 2V battery under fast, higher rate. Charge rate 0.251 -
®
0.40 C5. Properly FAST programmed Wi-iQ
(NexSys 2V battery). If not installed or no comm, charger will use manual
®
setup Ah and temp. Weekly equalization is needed.
For NexSys TPPL 2V battery under fast, higher rate. Charge rate 0.18 - 0.40
®
C5. Properly programmed Wi-iQ
2V battery). If not installed or no comm, charger will use manual setup Ah
and temp. Weekly equalization is needed.
For NexSys TPPL Bloc battery under normal charge. Charge rate 0.18 to
®
0.70 C5. Properly programmed Wi-iQ
TPPL Bloc battery). If not installed or no comm, charger will use manual
setup Ah and temp. Weekly equalization is needed.
For NexSys ATP 2V battery under fast, higher rate. Charge rate 0.2 to
®
0.5 C5. Properly FAST programmed Wi-iQ
(NexSys ATP 2V). If not installed or no communication, charger will use
®
setup Ah and temperature. Float ON have to be set. I
[Battery Voltage x Battery Capacity]/1000 x 0,1).
For Enersys lithium battery only. The charger is communicating with
®
the Enersys lithium BMS through the CANBUS, the BMS is driving
®
the charger and then the setting of the charger is not compulsory.
Nevertheless, there are recommended parameters to set on the charger.
battery monitoring device (NexSys
®
battery monitoring device
®
battery monitoring device (NexSys
®
battery monitoring device (NexSys
®
battery monitoring device
®
Float
®
BLOC
®
2V battery). If not
®
TPPL
®
®
= Round (roundup
