- Page 1 Charger OWNER’S MANUAL www.enersys.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ........3 Features ..........4 Technical Information ....... 4 Safety Precautions ......6 Installation ........7 Operating Instructions ..... 8 Menu and Display Information ..9 Maintenance and Service ....11... -
Page 3: Introduction
For service, contact your sales representative or visit: https://www.enersys.com/en/sales-services/ Your Safety and the Safety of Others is Very Important You may be seriously injured if you don’t WARNING follow these and other related instructions. -
Page 4: Features & Information
FEATURES & INFORMATION Features • Microprocessor-controlled. • HF modular technology with efficiency up to • Communicates with BMS via CAN. 93%. • Embedded multi-CAN protocols. 4.3 ‘ LCD display • Internal fans and filter. is used to display charging process parameters. •... - Page 5 LI-EC3 7T24V/150 4*2.5mm 60 mm LI-EC3 7T24V/200 4*2.5mm 70 mm LI-EC3 7T48V/150 4*2.5mm 60 mm LI-EC3 7T48V/200 4*4mm 70 mm LI-EC3 7T48V/250 4*6mm 95 mm Size Contact your EnerSys ® Representative for other types. Compartment 1 Compartment 2 Compartment 3...
-
Page 6: Safety Precautions
SAFETY Safety Precautions • Must be used in conformance with its indicated • The shipping pallet must be WARNING level of protection, and must never come into removed for proper and safe operations. contact with water. • This manual contains important safety and •... -
Page 7: Installation
If wall mounted, make sure that the surface is free of vibrations and the charger is mounted in a EU Declaration vertical position; if floor mounted, make sure that the EnerSys hereby declares that the chargers in ® surfaces are free of vibration, water, and humidity. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Operating Instructions Charging Process 1. Connect the charger input power. 2. Connect the charging plug of the charger to the charging socket of the battery. 3. Turn on the power switch, and the charger will display the welcome interface. After a few seconds, it will automatically enter the main charging interface (Figure 1). -
Page 9: Menu & Display
MENU & DISPLAY Menu and Display Information Control Panel Features Description ON/OFF: Stop and restart battery charge P- x : Represents the module type C- x : Represents the type of charging protocol Charging parameter display area System time and date Charging status display area Battery: Detailed battery information during charging... - Page 10 USB stick. Setting Information Click “Setting “ (Figure 7) to enter the “Setting” interface. This function requires a password to gain access to service level menus by authorized EnerSys service ® personnel. Figure 6 Figure 7...
-
Page 11: Maintenance And Service
MAINTENANCE & SERVICE Maintenance and Service Instructions for removing filter WARNING THERE ARE DANGEROUS VOLTAGES WITHIN THE BATTERY CHARGER CABINET. ONLY A • Remove the filter support. QUALIFIED PERSON SHOULD ATTEMPT TO ADJUST • Remove the screws above the filter support. OR SERVICE THIS BATTERY CHARGER. - Page 12 © 2024 EnerSys. All rights reserved. Unauthorized distribution prohibited. Trademarks and logos are the property of EnerSys and its affiliates, except CE and UK CA, which are not the property of EnerSys. Subject to revisions without prior notice. E.&O.E. S AMER-EN-OM-ELI-CH 0924...
