OPERATING INSTRUCTIONS

Operating Instructions
Ref Function
1
Graphical display
GREEN charge
2
complete indicator
Navigate LEFT/ESC
3
button
4
Navigate UP button
YELLOW charging
5
indicator
6
USB port
Navigate DOWN
7
button
8
RED fault indicator
BLUE AC supply
9
indicator
Navigate RIGHT/
10
EQUALIZE button
ENTER/STOP and
11
START button
Charge Operation
Charger idle display: With the charger in wait mode (no
battery connected) and without pressing the ENTER/
STOP and START button, the display will show the
following information:
Reference Description
1 Charger DC Voltage
2 Selected Charge Profile
3 Firmware Version
4 Connect Battery
System Time and Date
5
10 10
Description
Display charger operation
info/menus
OFF = charger off or battery
not available
FLASHING = cooling phase
ON = battery ready and
available
Enter main menu/Scroll left/
Exit menus
Navigate menus/Change
values
OFF = charger off or battery
not available
ON = charging in progress
Download memos/Upload
software
Navigate menus/Change
values
OFF = no fault
FLASHING = ongoing fault
detected
ON = fault
OFF = AC missing
ON = AC present
Scroll right/Start equalize or
desulfation
Select menu items/Enter
values/Stop and restart
battery charge
1
4
4
2 3
9
10
11
5 6 7 8
Control Panel Features
1 2 3
5
Charger Idle Display
