The TMR Wireless Field Bus System is similar to the legacy Johnson Controls
and ZFR1810 Series wireless systems, but there are several important differences. The following list
shows an overview of those differences:
• The TMR connects directly to the MS/TP bus of the controller with the controller running in
MS/TP mode.
• The TMR can support any Johnson Controls or third-party BACnet MS/TP controller. The
ZFR18xx radios only work with select Johnson Controls field controllers.
• The TMR system does not support Johnson Controls WRZ Series Wireless Sensors.
• Multiple MS/TP controllers can connect to a single TMR. The ZFR18xx radios can only connect
to a single controller.
Use the TMR wireless routers in the following applications:
• Indoor, intra-building applications
• Outdoor rooftop applications in a weather-appropriate, outdoor-rated enclosure

CEG and TMR System components

The CEG and TMR Wireless Field Bus System contains a CEG, TMR routers, and various BACnet MS/
TP equipment. One of the TMR routers in the system is configured as coordinator. See the following
table for component details.
Table 3: CEG and TMR System components
Product code Component description
number
SE-CEG1001-0 Connected Equipment Gateway, North
America
SE-CEG1001-1 Connected Equipment Gateway,
International
SE-CEG1001-E Connected Equipment Gateway,
Europe
SE-CEG1001-C Connected Equipment Gateway, China
SE-CEG1001-T Connected Equipment Gateway,
Taiwan
CEGPNL1001-0 Connected Equipment Gateway Panel
CEGPNL1002-0 Connected Equipment Gateway Panel
and TMR
JC-TMR2400-0 Transparent Wireless Router, 100mW
(20dBm), North America
JC-TMR2400-0E TMR Wireless Router, 10mW, (10dBm)
Europe and Japan
JC-TMR2400-0C TMR Wireless Router, 10mW (10dBm),
China
JC-TMR2400-0T TMR Wireless Router, 100mW
(20dBm), Taiwan
You can connect the TMR to YORK
enabled field controllers (WEFC). The TMRs are transparent to the WEFCs and the CEG, and no
8
or third-party party chiller controllers to make them wireless
®
Johnson Controls
ZFR1830, ZFR1820,
®
Reference names
CEG
CEG panel
TMR coordinator, TMR router, TMR
repeater
Note: The JC-TMR2400-x operates
in all three modes.
