Introduction

This document describes technical details of the Connected Equipment Gateway (CEG) and its
use with the Transparent MS/TP Router (TMR) Series Wireless System and the BACnet® MS/TP
controllers that the CEG manages.
Use this document for additional information about how to install, commission, maintain, and
troubleshoot the CEG and the TMR Wireless System. Also included is a brief technical background
on the wireless technology that the system uses.
Table 1: CEG and TMR related documentation
For information about
Locating, mounting, and wiring the TMR
Locating, mounting, and wiring the CEG
Locating, mounting, and wiring the CEG Panel
The local user interface for the CEG
Detailed information about the CEG and TMR
Correctly applying wireless
Detailed information about cybersecurity
practices
Table 2: Related wireless documentation
For information about
Testing the wireless signal strength between the
TMRs
Understanding MS/TP communications
Installation and setup of the SC-EQUIP (SC-EQ)

Applications

You can use the following methods to stream chiller data through the CEG to the Connected
Equipment Portal (CEP):
• Wireless by adding the TMR wireless router to the chiller's BACnet MS/TP port
• Directly, or wired, by connecting to the same BACnet MS/TP trunk as the chiller
Note: The CEG supports BACnet MS/TP devices at BACnet protocol revision 4 or later.
However, for optimal network performance, use devices at BACnet protocol revision 15 or
later.

CEG and TMR System overview

The CEG uses BACnet MS/TP open protocol to monitor chiller operation. The gateway can
communicate either through hardwired RS-485 or wirelessly, using mesh network technology with
self-healing capabilities. The CEG then aggregates, packages, and transmits the data to the Johnson
CEG and TMR Technical Bulletin
Document title and number
TMR Series Wireless Router Installation Guide (Part
No. 24-11461-00020)
CEG Installation Guide (Part No. 24-11460-00034)
CEG Panel Installation Guide (Part No.
24-11460-00050)
CEG and TMR User Guide (LIT-12013890)
CEG and TMR Technical Bulletin (LIT-12013900)
TMR Wireless Best Practices (LIT-12013954)
Smart Connected Chillers Hardening Requirements
(Part No. GPS0030-CE-20220429-EN)
Document title and number
ZFR-HPSST-0 High Power Wireless Sensing System
Installation Guide (Part No. 24-11461-00012)
MS/TP Communications Bus Technical Bulletin
(LIT-12011034)
SC-EQ COMMUNICATION CARD 035-25087-000,
Form 450.50-N1 (1220)
