• If you use TMR wireless options, consider where you can place the panel to limit the number of
hops and distance between wireless endpoints.
• Cellular communication for streaming out data. You can use your own cellular device as a
rudimentary gauge to test the available signal. If your cellular device is unable to get a signal,
a cellular modem may also have trouble getting a signal.
• If you connect the CEG to York chillers with Smart Connected Equipment boards (SC-EQ),
ensure the SC-EQ all run on version 3.5.x.x or higher to ensure compatibility with CEG.

Performance considerations for third-party BACnet devices

Network performance can degrade when you add third-party devices on the same MS/TP trunk if
those devices do not meet the minimum requirements in Table 4. Actual job experience has shown
as few as five devices can create significant performance issues; although other variables can affect
performance, such as the number of objects per device. To improve network performance, ensure
that third-party devices also meet the preferred requirements.
Table 4: Third-Party BACnet device performance requirements
MS/TP trunk and BACnet services
Devices on MS/TP trunk
BACnet services

Installing the CEG Panel

Refer to the CEG Panel Installation Guide (Part No. 24-11460-00050) and the TMR Installation Guide
(Part No. 24-11461-00020) for details about how to install the CEG.
Important: If you use TMR wireless with more than four chillers, install a second TMR
coordinator in the panel and configure the AREA and Personal Area Network (PAN) OFFSET to
be unique between the two networks.

Installing the TMR

About this task:
Refer to the TMR Installation Guide (Part No. 24-11461-00020) for the full details about how to install
the TMR.
10
MS/TP master device
Baud rate 38,400 bps
Application Layer Protocol Data
Unit (APDU) size 480 bytes
APDU size 200 bytes
Segmentation on MS/TP
BACnet version 1 revision 4 or
later
BACnet version 1 revision 15 or
later
Device profile of B-SA or B-SS
BACnet certified
+ Read Property Multiple,
Execute
+ Subscribe COV, Execute
+ Write Property Multiple,
Execute
Johnson Controls
Requirement
Required
Minimum
Acceptable
Preferred
Acceptable
Minimum
Preferred
Minimum
Minimum
Preferred
Preferred
Preferred
