-- SGP-600 --
(NOVA PREMIERE™)
Installation Instructions
Jaypro strongly recommends that all portable soccer goals be
anchored, to prevent accidental tip-over and serious injury.
Never climb, or allow anyone else to climb on the frame or net.
Call Jaypro Sports Equipment at 1-800-243-0533
during regular business hours for technical support.
www.jaypro.com
Rev-C
6/21
Page 1 of 14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jaypro Sports NOVA PREMIERE SGP-600
Summary of Contents for Jaypro Sports NOVA PREMIERE SGP-600
- Page 1 Jaypro strongly recommends that all portable soccer goals be anchored, to prevent accidental tip-over and serious injury. Never climb, or allow anyone else to climb on the frame or net. Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com...
- Page 2 JAYPRO SPORTS NOVA PREMIERE™ SGP-600 (QTY: SINGLE GOAL) ITEM IMAGE DESCRIPTION 4” SOCCER CROSSBAR x 280” P/N: SG-001X 2” x 4” x 98” SOCCER BASE P/N: SG-002B 2” x 4” x 280” SOCCER REAR CROSSBAR P/N: SG-003XB 4” SOCCER UPRIGHT RIGHT P/N: SG-600USR 4”...
- Page 3 Unpack all parts and check against parts list to ensure that all have been included. Inspect all parts for damage. Report any damages to the trucking company. ITEM IMAGE DESCRIPTION EUROPEAN BACKSTAY LEFT P/N: SG-EBS4L 2” x 4” LOWER CORNER FITTING P/N: SG-A 7”...
- Page 4 OPTIONAL WHEEL KIT FOR PORTABLE SOCCER GOALS (P/N: NSGWK) NOTE: Kit includes four wheel assemblies. Wheel assemblies may be used in pairs, (i.e. two per goal) which would require lifting one end of goal to move. Alternately, four wheel assemblies may be installed on a soccer goal to avoid the need to lift. At least two people are required to properly move a soccer goal, to prevent personal injury or damage to the goal.
-
Page 5: Important Notice
1. Soccer goals must be securely anchored at all times. 2. Before each use, check to make sure all Safety/Warning labels are present and legible (see label drawing). If any are missing, contact your dealer or Jaypro Sports for replacement Safety / Warning labels. - Page 6 Rev-C 6/21 Page 6 of 14...
- Page 7 Rev-C 6/21 Page 7 of 14...
- Page 8 Rev-C 6/21 Page 8 of 14...
- Page 9 Bottom Goal Assembly: 1. Insert one lower corner fitting into each end of the 2” x 4” x 280” rear crossbar. 2. Install hardware loosely as shown. Rev-C 6/21 Page 9 of 14...
- Page 10 Bottom Goal Assembly: 3. Stand the front of the soccer goal into the upright position. One person should securely hold the face of the goal in position. a. Note: If a wheel kit is to be installed, slide the nut bars for the wheel kit into each base member.
- Page 11 6. Install the auxiliary soccer backstay and line up the nut bar. Note that if the plates don’t line up, flip the auxiliary soccer backstay. Install hardware loosely. Once all parts are aligned, tighten all hardware. Rev-C 6/21 Page 11 of 14...
- Page 12 Place labels according to the diagram below. Always inspect goals before each use to ensure that all labels are in place and legible. Contact your dealer or Jaypro Sports for replacement labels. Label Placement Instructions:...
- Page 13 Jaypro strongly recommends that all portable soccer goals be anchored, to prevent accidental tip-over and serious injury. Never climb, or allow anyone else to climb on the frame or net. Final Adjustments: Check to make sure the soccer goal frame is properly aligned and square. Securely tighten all button head and hex head hardware.
- Page 14 Anchoring Systems: IMPORTANT – PORTABLE SOCCER GOALS SHOULD BE ANCHORED AT ALL TIMES. There are three categories of anchors suitable for securing soccer goals. Semi-Permanent In-Ground Anchors: SGA-60 Semi-permanent in-ground anchors are the most secure type of anchor, as they are not dependent on soil conditions or subject to improper placement or dislodging.
