1 OR 2
5
11
DETAIL A
F
B
9
2
HM6239
7/16" x 2 1/2" QUICK RELEASE PIN w/ LANYARD
10
2
HS1233
#10-16 x 5/16" THREAD FORM SCREW, SS
11
4
HN1230
3/8"-16 NYLON JAM NUT, SS
12
4
HS5163
3/8"-16 x 2 3/4" BUTTON HD HEX SCREW, SS
13
10
HM4104
NET STAKE 1/4" x 9"
14
1
NW0047
3/4" WIDE WHITE ONE WRAP x 4 YD
15
8
RR5023
1 1/2" x 24" INDOOR ANTI-SKID PADS
16
1
SEYL-24NHP
NET (NOT INCLUDED)
ITEM
QTY
PART #
DESCRIPTION
VARIES
8
VARIES
12
DETAIL D
(TYP PIPE TO PIPE CONNECTION)
D
7
A
5
1
1
2
1
3
2
4
2
5
2
6
1
7
2
8
8
ITEM
QTY
6
1 OR 2
11
C
DETAIL B
SEYL-LW
LEFT UPRIGHT
SEYL-RW
RIGHT UPRIGHT
SEYL-A
BASE FRAME
SEYL-FA2
BACKSTAY EXTENSION TUBE
SEYL-EA2
REAR BACKSTAY
SEYL-D
MIDDLE CROSSBAR
SEYL-C
END CROSSBAR
HM5051
SNAP BUTTON
PART #
DESCRIPTION
G
7
1
E
12
5
3
3
DETAIL C
(PIN DETAIL)
9
MODEL NUMBER:
PRODUCT NAME:
QUICK SET-UP SOCCER GOAL
976 Hartford Turnpike
Waterford, CT 06385 USA
(800)243−0533 Fax: (800)988−3363
DATE:
www.jaypro.com
7/7/2009
5
8
4
8
10
CHECKED BY:
SEYL-824
WVB
PAGE:
DRAWN BY:
1 OF 2
Moune T.
Advertisement
Related Manuals for Jaypro Sports SEYL-824
Summary of Contents for Jaypro Sports SEYL-824
- Page 1 SEYL-RW RIGHT UPRIGHT HN1230 3/8"-16 NYLON JAM NUT, SS SEYL-A BASE FRAME MODEL NUMBER: CHECKED BY: SEYL-824 HS5163 3/8"-16 x 2 3/4" BUTTON HD HEX SCREW, SS SEYL-FA2 BACKSTAY EXTENSION TUBE PRODUCT NAME: HM4104 NET STAKE 1/4" x 9" SEYL-EA2...
- Page 2 FIGURE: 1 DETAIL G FIGURE: 2 RE-INSERT PIN (ITEM 9) APPROXIMATELY SPACED 15" APART MODEL NUMBER: CHECKED BY: SEYL-824 PRODUCT NAME: QUICK SET-UP SOCCER GOAL DETAIL E 976 Hartford Turnpike (OPTIONAL INDOOR FEET) Waterford, CT 06385 USA (800)243−0533 Fax: (800)988−3363...
- Page 3 4) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS. 5) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: (1) 9/16” Socket or Box Wrench...
- Page 4 (8) Attach rear backstay (item 5) to upright using hardware shown in Detail A. (9) Insert one backstay extension tube (item 4) into each rear backstay. (Note: insert end with single hole and snap pin, see Detail C). (10) Lift rear backstay and raise base frame into vertical position. Assemble rear backstay into base frame by inserting quick release pin.
